Sel SEL-421 - Interface Board #1 Control Inputs; Interface Board #2 Control Inputs

R.10.7
Date Code 20111215 Reference Manual SEL-421 Relay
Settings
Global Settings
Make Table 10.8 settings for Interface Board #1 when Global enable setting
EICIS := Y.
Make Table 10.9 settings for Interface Board #2 when Global enable setting
EICIS := Y.
Table 10.8 Interface Board #1 Control Inputs
Label Prompt Default Value
IN201P
a
a
Setting is not available for interface boards INT2, INT4, INT7, and INT8. Set to Global setting
GINP when EICIS := N.
Input IN201 Pickup Level (15–265 Vdc) 85
b
b
Factory set at 18 for 24/48 Vdc nominal power supply, 36 for 48/125 Vdc nominal power
supply, and 85 for 125/240 Vdc power supply. See Control Inputs on page U.2.5 for setting
guidelines.
•
•
•
•
•
•
•
•
•
IN208P
a
Input IN208 Pickup Level (15–265 Vdc) 85
b
IN201PU Input IN201 Pickup Delay (0.0000–5 cyc
c
)
c
If the interface board has more than eight input contacts, the upper range is 1 cycle.
0.1250
d
d
Set to Global setting IN2XXD when EICIS :-= N
IN201DO Input IN201 Dropout Delay (0.0000–5 cyc
c
) 0.1250
d
•
•
•
•
•
•
•
•
•
IN2mmPU
e
e
mm is the number of available input contacts on the interface board.
Input IN2mm
e
Pickup Delay (0.0000–5 cyc
c
) 0.1250
d
IN2mmDO
e
Input IN2mm
e
Dropout Delay (0.0000–5 cyc
c
) 0.1250
d
Table 10.9 Interface Board #2 Control Inputs
Label Prompt Default Value
IN301P
a
a
Setting is not available for interface boards INT2, INT4, INT7, and INT8. Set to Global setting
GINP when EICIS := N.
Input IN301 Pickup Level (15–265 Vdc) 85
b
b
Factory set at 18 for 24/48 Vdc nominal power supply, 36 for 48/125 Vdc nominal power
supply, and 85 for 125/240 Vdc power supply. See Control Inputs on page U.2.5 for setting
guidelines.
•
•
•
•
•
•
•
•
•
IN308P
a
Input IN308 Pickup Level (15–265 Vdc) 85
b
IN301PU Input IN301 Pickup Delay (0.0000–5 cyc
c
)
c
If the interface board has more than eight input contacts, the upper range is 1 cycle.
0.1250
d
d
Set to Global setting IN3XXD when EICIS := N.
IN301DO Input IN301 Dropout Delay (0.0000–5 cyc
c
) 0.1250
d
•
•
•
•
•
•
•
•
•
IN3mmPU
e
e
mm is the number of available input contacts on the interface board.
Input IN3mm
e
Pickup Delay (0.0000–5 cyc
c
) 0.1250
d
IN3mmDO
e
Input IN3mm
e
Dropout Delay (0.0000–5 cyc
c
) 0.1250
d
