Sel SEL-421 - Three-Pole Reclose Settings

R.10.32
SEL-421 Relay Reference Manual Date Code 20111215
Settings
Group Settings
SPRCD Single-Pole Reclaim Time Delay
(1–99999 cycles)
900
SPRI Single-Pole Reclose Initiation
(SEL
OGIC Equation)
SPT
SP1CLS Single-Pole BK1 Reclose Supervision
(SEL
OGIC Equation)
b
1
SP2CLS Single-Pole BK2 Reclose Supervision
(SEL
OGIC Equation)
b
1
a
Adjust all timers in 1-cycle steps.
b
These settings cannot be set to NA or to logical 0.
Table 10.67 Three-Pole Reclose Settings
a
a
Adjust all timers in 1-cycle steps.
Label Prompt Default Value
3POISC Three-Pole Open Interval Supervision
(SEL
OGIC Equation)
b
b
These settings cannot be set to NA or to logical 0.
1
3POISD Three-Pole Open Interval Supervision
Delay (OFF, 1–99999 cycles)
1
3POID1 Three-Pole Open Interval 1 Delay
(1–99999 cycles)
180
3POID2 Three-Pole Open Interval 2 Delay
(1–99999 cycles)
180
3POID3 Three-Pole Open Interval 3 Delay
(1–99999 cycles)
180
3POID4 Three-Pole Open Interval 4 Delay
(1–99999 cycles)
180
3PFARC Three-Pole Fast Automatic Reclose Enable
(SEL
OGIC Equation)
NA
3PFOID Three-Pole Fast Open Interval Delay
(1–99999 cycles)
60
3PRCD Three-Pole Reclaim Time Delay
(1–99999 cycles)
900
3PRI Three-Pole Reclose Initiation
(SEL
OGIC Equation)
3PT AND NOT (M2PT
OR Z2GT OR M3PT OR
Z3GT OR SOTFT)
79SKP Skip Reclosing Shot (SEL
OGIC Equation) NA
3P1CLS Three Pole BK 1 Reclose Supervision
(SEL
OGIC Equation)
b
1
3P2CLS Three Pole BK 2 Reclose Supervision
(SEL
OGIC Equation)
b
1
Table 10.66 Single-Pole Reclose Settings
a
(Sheet 2 of 2)
Label Prompt Default Value
