SEL-421 Relay Reference Manual Date Code 20111215
Relay Word Bits
Row List
185 AST32R Automation Sequencing Timer 32 reset
185 AST31R Automation Sequencing Timer 31 reset
185 AST30R Automation Sequencing Timer 30 reset
185 AST29R Automation Sequencing Timer 29 reset
185 AST28R Automation Sequencing Timer 28 reset
185 AST27R Automation Sequencing Timer 27 reset
185 AST26R Automation Sequencing Timer 26 reset
185 AST25R Automation Sequencing Timer 25 reset
Table A.33 Relay Word Bits: Automation Counters (Sheet 1 of 2)
Row Name Description
186 ACN08Q Automation Counter 8 output
186 ACN07Q Automation Counter 7 output
186 ACN06Q Automation Counter 6 output
186 ACN05Q Automation Counter 5 output
186 ACN04Q Automation Counter 4 output
186 ACN03Q Automation Counter 3 output
186 ACN02Q Automation Counter 2 output
186 ACN01Q Automation Counter 1 output
187 ACN16Q Automation Counter 16 output
187 ACN15Q Automation Counter 15 output
187 ACN14Q Automation Counter 14 output
187 ACN13Q Automation Counter 13 output
187 ACN12Q Automation Counter 12 output
187 ACN11Q Automation Counter 11 output
187 ACN10Q Automation Counter 10 output
187 ACN09Q Automation Counter 9 output
188 ACN24Q Automation Counter 24 output
188 ACN23Q Automation Counter 23 output
188 ACN22Q Automation Counter 22 output
188 ACN21Q Automation Counter 21 output
188 ACN20Q Automation Counter 20 output
188 ACN19Q Automation Counter 19 output
188 ACN18Q Automation Counter 18 output
188 ACN17Q Automation Counter 17 output
189 ACN32Q Automation Counter 32 output
189 ACN31Q Automation Counter 31 output
189 ACN30Q Automation Counter 30 output
189 ACN29Q Automation Counter 29 output
189 ACN28Q Automation Counter 28 output
189 ACN27Q Automation Counter 27 output
Table A.32 Relay Word Bits: Automation Sequencing Timers (Sheet 3 of 3)
Row Name Description
