Date Code 20111215 Reference Manual SEL-421 Relay
Relay Word Bits
Row List
288 LB_DP05 Local Bit 05 Status Display (SELOGIC Equation)
288 LB_DP04 Local Bit 04 Status Display (SEL
OGIC Equation)
288 LB_DP03 Local Bit 03 Status Display (SELOGIC Equation)
288 LB_DP02 Local Bit 02 Status Display (SEL
OGIC Equation)
288 LB_DP01 Local Bit 01 Status Display (SEL
OGIC Equation)
289 LB_DP16 Local Bit 16 Status Display (SEL
OGIC Equation)
289 LB_DP15 Local Bit 15 Status Display (SEL
OGIC Equation)
289 LB_DP14 Local Bit 14 Status Display (SEL
OGIC Equation)
289 LB_DP13 Local Bit 13 Status Display (SEL
OGIC Equation)
289 LB_DP12 Local Bit 12 Status Display (SEL
OGIC Equation)
289 LB_DP11 Local Bit 11 Status Display (SEL
OGIC Equation)
289 LB_DP10 Local Bit 10 Status Display (SELOGIC Equation)
289 LB_DP09 Local Bit 09 Status Display (SEL
OGIC Equation)
290 LB_DP24 Local Bit 24 Status Display (SEL
OGIC Equation)
290 LB_DP23 Local Bit 23 Status Display (SEL
OGIC Equation)
290 LB_DP22 Local Bit 22 Status Display (SEL
OGIC Equation)
290 LB_DP21 Local Bit 21 Status Display (SEL
OGIC Equation)
290 LB_DP20 Local Bit 20 Status Display (SEL
OGIC Equation)
290 LB_DP19 Local Bit 19 Status Display (SEL
OGIC Equation)
290 LB_DP18 Local Bit 18 Status Display (SEL
OGIC Equation)
290 LB_DP17 Local Bit 17 Status Display (SEL
OGIC Equation)
291 LB_DP32 Local Bit 32 Status Display (SEL
OGIC Equation)
291 LB_DP31 Local Bit 31 Status Display (SEL
OGIC Equation)
291 LB_DP30 Local Bit 30 Status Display (SEL
OGIC Equation)
291 LB_DP29 Local Bit 29 Status Display (SEL
OGIC Equation)
291 LB_DP28 Local Bit 28 Status Display (SEL
OGIC Equation)
291 LB_DP27 Local Bit 27 Status Display (SEL
OGIC Equation)
291 LB_DP26 Local Bit 26 Status Display (SEL
OGIC Equation)
291 LB_DP25 Local Bit 25 Status Display (SEL
OGIC Equation)
Tabl e A . 54 RTC Re mot e Dig ita l St a tus (Sheet 1 of 2)
Row Bit Name Description
292 RTCAD08 RTC Remote Data Bits, Channel A, bit 8
292 RTCAD07 RTC Remote Data Bits, Channel A, bit 7
292 RTCAD06 RTC Remote Data Bits, Channel A, bit 6
292 RTCAD05 RTC Remote Data Bits, Channel A, bit 5
292 RTCAD04 RTC Remote Data Bits, Channel A, bit 4
292 RTCAD03 RTC Remote Data Bits, Channel A, bit 3
292 RTCAD02 RTC Remote Data Bits, Channel A, bit 2
292 RTCAD01 RTC Remote Data Bits, Channel A, bit 1
Table A.53 Relay Word Bits: Local Bit Supervision and Status
(Sheet 2 of 2)
Row Bit Name Description
