DNP3 Communications
DNP3 Documentation
interfaces on the SEL-421. The TEST DNP command operates by object and
index number, so it works equally well with custom mapping and the default
DNP map.
When you are using the TEST DNP command to test DNP operation, the
Relay Word bit TESTDNP will be asserted to indicate that test mode is active.
The DNP status bit will also show forced status for any object variations that
include status.
DNP3 Documentation
Device Profile
Tab le 6.8 contains the standard DNP3 device profile information. Rather than
checkboxes in the example Device Profile in the DNP3 Subset Definitions,
only the relevant selections are shown.
Table 6.8 SEL-421 DNP3 Device Profile (Sheet 1 of 2)
Parameter Value
Vendor name Schweitzer Engineering Laboratories
Device name SEL-421 Relay
Highest DNP request level Level 2
Highest DNP response level Level 2
Device function Slave
Notable objects, functions,
and/or qualifiers supported
Virtual terminal
Maximum data link frame size transmitted/
received (octets)
292
Maximum data link retries Configurable, range 0 to 15
Requires data link layer confirmation Configurable by setting
Maximum application fragment size trans-
mitted/received (octets)
2048
Maximum application layer retries None
Requires application layer confirmation When reporting Event Data
Data link confirm time-out Configurable
Complete application fragment time-out None
Application confirm time-out Configurable
Complete Application response time-out None
Executes control WRITE binary outputs Always
Executes control SELECT/OPERATE Always
Executes control DIRECT OPERATE Always
Executes control DIRECT OPERATE-NO
ACK
Always
Executes control count greater than 1 Never
Executes control Pulse On Always
Executes control Pulse Off Always
Executes control Latch Off Always
Executes control Latch Off Always
Executes control Queue Never
