R.10.37
Date Code 20111215 Reference Manual SEL-421 Relay
Settings
Front-Panel Settings
Front-Panel Settings
Tabl e 1 0 .77 MIRRORED BITS Transmit Equations
Label Prompt Default Value
TMB1A NA
•
•
•
•
•
•
•
•
•
TMB8A NA
TMB1B NA
•
•
•
•
•
•
•
•
•
TMB8B NA
Table 10.78 Front-Panel Settings Categories
Settings Reference
Front-Panel Settings Table 10.79
Selectable Screens for the Front Panel Table 10.80
Selectable Operator Pushbuttons Table 10.81
Front-Panel Event Display Table 10.82
Local Control and Aliases Table 10.85
Display Points and Aliases
Boolean Display Points Table 10.83
Analog Display Points Table 10.84
Table 10.79 Front Panel Settings (Sheet 1 of 6)
Label Prompt Default Value
FP_TO Front Panel Display Time-Out
(OFF,1–60 min)
15
EN_LEDC Enable LED Asserted Color (R,G) G
TR_LEDC Trip LED Asserted Color (R,G) R
PB1_LED Pushbutton LED 1
(SEL
OGIC Equation)
NOT E3PT #SPT ENABLED
PB1_COL PB_LED Assert and Deassert Color
(Enter 2: R,G,A,O)
AO
PB2_LED Pushbutton LED 2
(SEL
OGIC Equation)
PLT02 #COMM SCHEME
ENABLED
PB2_COL PB_LED Assert and Deassert Color
(Enter 2: R,G,A,O)
AO
PB3_LED Pushbutton LED 3
(SEL
OGIC Equation)
NOT SG1 #ALT SETTINGS
PB3_COL PB_LED Assert and Deassert Color
(Enter 2: R,G,A,O)
AO
NOTE: See corresponding command
descriptions SET F on page R.9.41 to
set or show the Front-Panel settings.
