Sel SEL-421 - Relay Word Bits: Communications Card Status Points

R.A.72
SEL-421 Relay Reference Manual Date Code 20111215
Relay Word Bits
Row List
255 CCOUT06 Communications Card Output Point 6
255 CCOUT07 Communications Card Output Point 7
255 CCOUT08 Communications Card Output Point 8
Table A.45 Relay Word Bits: Communications Card Status Points
Row Name Description
256 CCSTA01 Communications Card Status Register Bit 16
256 CCSTA02 Communications Card Status Register Bit 15
256 CCSTA03 Communications Card Status Register Bit 14
256 CCSTA04 Communications Card Status Register Bit 13
256 CCSTA05 Communications Card Status Register Bit 12
256 CCSTA06 Communications Card Status Register Bit 11
256 CCSTA07 Communications Card Status Register Bit 10
256 CCSTA08 Communications Card Status Register Bit 9
257 CCSTA09 Communications Card Status Register Bit 8
257 CCSTA10 Communications Card Status Register Bit 7
257 CCSTA11 Communications Card Status Register Bit 6
257 CCSTA12 Communications Card Status Register Bit 5
257 CCSTA13 Communications Card Status Register Bit 4
257 CCSTA14 Communications Card Status Register Bit 3
257 CCSTA15 Communications Card Status Register Bit 2
257 CCSTA16 Communications Card Status Register Bit 1
258 CCSTA17 Communications Card Self-Test Status Register Bit 16
258 CCSTA18 Communications Card Self-Test Status Register Bit 15
258 CCSTA19 Communications Card Self-Test Status Register Bit 14
258 CCSTA20 Communications Card Self-Test Status Register Bit 13
258 CCSTA21 Communications Card Self-Test Status Register Bit 12
258 CCSTA22 Communications Card Self-Test Status Register Bit 11
258 CCSTA23 Communications Card Self-Test Status Register Bit 10
258 CCSTA24 Communications Card Self-Test Status Register Bit 9
259 CCSTA25 Communications Card Self-Test Status Register Bit 8
259 CCSTA26 Communications Card Self-Test Status Register Bit 7
259 CCSTA27 Communications Card Self-Test Status Register Bit 6
259 CCSTA28 Communications Card Self-Test Status Register Bit 5
259 CCSTA29 Communications Card Self-Test Status Register Bit 4
259 CCSTA30 Communications Card Self-Test Status Register Bit 3
259 CCSTA31 Communications Card Self-Test Status Register Bit 2
259 CCSTA32 Communications Card Self-Test Status Register Bit 1
Table A.44 Relay Word Bits: Communications Card Output Points
(Sheet 2 of 2)
Row Name Description
