R.9.45
Date Code 20111215 Reference Manual SEL-421 Relay
ASCII Command Reference
Description of Commands
SHO A
Use the SHO A command to show the Automation SELOGIC control
equations. See Section 3: SEL
OGIC Control Equation Programming for more
information on SEL
OGIC control equations.
SHO D
The SHO D command shows the serial port DNP3 remapping settings. To
view the general serial port DNP3 settings, use the Port settings (see SHO P
on page R.9.47). There is only one instance of the serial port DNP3 remapping
settings. The relay must have the optional serial port DNP3 protocol installed
to access these settings. For more information, see Section 6: DNP3
Communications.
SHO F
Use the SHO F command to show the relay front-panel settings. There is only
one instance for the Front Panel settings. See Section 5: Front-Panel
Operations in the User’s Guide for information on front-panel settings.
SHO G
Use the SHO G command to show the Global class settings. There is only one
instance for the Global class.
Tabl e 9. 11 4 SH O A Comm a nd
Command Description Access Level
SHO A Show the Automation SELOGIC control equa-
tion relay settings in Block 1.
1, B, P, A, O, 2
SHO A n
a
a
Parameter n = 1–10 for Block 1 through Block 10.
Show the Automation SELOGIC control equa-
tion relay settings in Block n.
1, B, P, A, O, 2
Tabl e 9. 11 5 S H O D C omm and
Command Description Access Level
SHO D Show the serial port DNP3 remapping settings. P, A, O, 2
SHO D label Show the serial port DNP3 remapping settings,
beginning at setting label.
P, A, O, 2
NOTE: This does not display
mapping information for DNP
LAN/WAN.
Table 9.116 SHO F Command
Command Description Access Level
SHO F Show the Front Panel relay settings, beginning
at the first setting in this class.
1, B, P, A, O, 2
SHO F label Show the Front Panel relay settings, beginning
at the settings label label.
1, B, P, A, O, 2
