Sel SEL-421 - Relay Word Bits: Local Bit Supervision and Status

R.A.78
SEL-421 Relay Reference Manual Date Code 20111215
Relay Word Bits
Row List
283 * Reserved
283 * Reserved
Table A.53 Relay Word Bits: Local Bit Supervision and Status
(Sheet 1 of 2)
Row Bit Name Description
284 LB_SP08 Local Bit 08 Supervision (SELOGIC Equation)
284 LB_SP07 Local Bit 07 Supervision (SEL
OGIC Equation)
284 LB_SP06 Local Bit 06 Supervision (SEL
OGIC Equation)
284 LB_SP05 Local Bit 05 Supervision (SEL
OGIC Equation)
284 LB_SP04 Local Bit 04 Supervision (SEL
OGIC Equation)
284 LB_SP03 Local Bit 03 Supervision (SELOGIC Equation)
284 LB_SP02 Local Bit 02 Supervision (SEL
OGIC Equation)
284 LB_SP01 Local Bit 01 Supervision (SEL
OGIC Equation)
285 LB_SP16 Local Bit 16 Supervision (SEL
OGIC Equation)
285 LB_SP15 Local Bit 15 Supervision (SEL
OGIC Equation)
285 LB_SP14 Local Bit 14 Supervision (SEL
OGIC Equation)
285 LB_SP13 Local Bit 13 Supervision (SEL
OGIC Equation)
285 LB_SP12 Local Bit 12 Supervision (SEL
OGIC Equation)
285 LB_SP11 Local Bit 11 Supervision (SEL
OGIC Equation)
285 LB_SP10 Local Bit 10 Supervision (SEL
OGIC Equation)
285 LB_SP09 Local Bit 09 Supervision (SEL
OGIC Equation)
286 LB_SP24 Local Bit 24 Supervision (SEL
OGIC Equation)
286 LB_SP23 Local Bit 23 Supervision (SEL
OGIC Equation)
286 LB_SP22 Local Bit 22 Supervision (SEL
OGIC Equation)
286 LB_SP21 Local Bit 21 Supervision (SEL
OGIC Equation)
286 LB_SP20 Local Bit 20 Supervision (SEL
OGIC Equation)
286 LB_SP19 Local Bit 19 Supervision (SEL
OGIC Equation)
286 LB_SP18 Local Bit 18 Supervision (SEL
OGIC Equation)
286 LB_SP17 Local Bit 17 Supervision (SEL
OGIC Equation)
287 LB_SP32 Local Bit 32 Supervision (SEL
OGIC Equation)
287 LB_SP31 Local Bit 31 Supervision (SEL
OGIC Equation)
287 LB_SP30 Local Bit 30 Supervision (SEL
OGIC Equation)
287 LB_SP29 Local Bit 29 Supervision (SEL
OGIC Equation)
287 LB_SP28 Local Bit 28 Supervision (SEL
OGIC Equation)
287 LB_SP27 Local Bit 27 Supervision (SELOGIC Equation)
287 LB_SP26 Local Bit 26 Supervision (SEL
OGIC Equation)
287 LB_SP25 Local Bit 25 Supervision (SEL
OGIC Equation)
288 LB_DP08 Local Bit 08 Status Display (SEL
OGIC Equation)
288 LB_DP07 Local Bit 07 Status Display (SEL
OGIC Equation)
288 LB_DP06 Local Bit 06 Status Display (SEL
OGIC Equation)
Table A.52 Pushbuttons, Pushbutton LEDs, and Target LEDs for new HMI
(Sheet 2 of 2)
Row Bit Name Description
