Relay Word Bits
Row List
87 * Reserved
87 * Reserved
87 * Reserved
Table A.21 Relay Word Bits: Local Bits
Row Name Description
88 LB08 Local Bit 8
88 LB07 Local Bit 7
88 LB06 Local Bit 6
88 LB05 Local Bit 5
88 LB04 Local Bit 4
88 LB03 Local Bit 3
88 LB02 Local Bit 2
88 LB01 Local Bit 1
89 LB16 Local Bit 16
89 LB15 Local Bit 15
89 LB14 Local Bit 14
89 LB13 Local Bit 13
89 LB12 Local Bit 12
89 LB11 Local Bit 11
89 LB10 Local Bit 10
89 LB09 Local Bit 9
90 LB24 Local Bit 24
90 LB23 Local Bit 23
90 LB22 Local Bit 22
90 LB21 Local Bit 21
90 LB20 Local Bit 20
90 LB19 Local Bit 19
90 LB18 Local Bit 18
90 LB17 Local Bit 17
91 LB32 Local Bit 32
91 LB31 Local Bit 31
91 LB30 Local Bit 30
91 LB29 Local Bit 29
91 LB28 Local Bit 28
91 LB27 Local Bit 27
91 LB26 Local Bit 26
91 LB25 Local Bit 25
Table A.20 Relay Word Bits: Open and Close Command (Sheet 2 of 2)
Row Name Description
