Sel SEL-421 - Settings Group Selection; Data Reset Control

R.10.8
SEL-421 Relay Reference Manual Date Code 20111215
Settings
Global Settings
Make Table 10.11 settings when Global enable setting EDRSTC := Y.
Make Table 10.12 settings when Global enable setting EGADVS := Y.
Table 10.10 Settings Group Selection
Label Prompt Default Value
SS1 Select Setting Group 1 (SELOGIC Equation) PB3 AND
NOT SG1
SS2 Select Setting Group 2 (SEL
OGIC Equation) PB3 AND SG1
SS3 Select Setting Group 3 (SEL
OGIC Equation) NA
SS4 Select Setting Group 4 (SELOGIC Equation) NA
SS5 Select Setting Group 5 (SEL
OGIC Equation) NA
SS6 Select Setting Group 6 (SEL
OGIC Equation) NA
TGR Group Change Delay (1–54000 cycles) 180
Tabl e 1 0 .11 Da ta Re s et Con tro l
Label Prompt Default Value
RST_DEM Reset Demand Metering (SELOGIC Equation) NA
RST_PDM Reset Peak Demand Metering (SEL
OGIC Equation) NA
RST_ENE Reset Energy Metering (SEL
OGIC Equation) NA
RSTMML Reset Maximum/Minimum Line (SEL
OGIC Equation) NA
RSTMMB1 Reset Maximum/Minimum Breaker 1
(SEL
OGIC Equation)
NA
RSTMMB2 Reset Maximum/Minimum Breaker 2
(SEL
OGIC Equation)
NA
RST_BK1 Reset Monitoring Breaker 1 (SEL
OGIC Equation) NA
RST_BK2 Reset Monitoring Breaker 2 (SEL
OGIC Equation) NA
RST_BAT Reset Battery Monitoring (SEL
OGIC Equation) NA
RST_79C Reset Recloser Shot Count Accumulators (SEL
OGIC
Equation)
NA
RSTTRGT Target Reset (SEL
OGIC Equation) NA
RSTFLOC Reset Fault Locator (SEL
OGIC Equation) NA
RSTDNPE Reset DNP Fault Summary Data (SEL
OGIC Equation) TRGTR
Table 10.12 Frequency Estimation (Sheet 1 of 2)
Label Prompt Default Value
EAFSRC Alternate Frequency Source
(SEL
OGIC Equation)
NA
VF01 Local Frequency Source 1 (ZERO, VAY, VBY, VCY,
VAZ, VBZ, VCZ)
VAY
VF02 Local Frequency Source 2 (ZERO, VAY, VBY, VCY,
VAZ, VBZ, VCZ)
VBY
VF03 Local Frequency Source 3 (ZERO, VAY, VBY, VCY,
VAZ, VBZ, VCZ)
VCY
VF11 Alternate Frequency Source 1 (ZERO, VAY, VBY,
VCY, VAZ, VBZ, VCZ)
ZERO
