R.9.50
SEL-421 Relay Reference Manual Date Code 20111215
ASCII Command Reference
Description of Commands
If you attempt to acknowledge an event summary that you have not viewed on
the present port with the SUM NEXT command, the relay responds,
Event
summary number n has not been viewed with the NEXT option
.
SUM NEXT
Use the SUM N command to view the oldest (next) unacknowledged event
summary.
TARGET
The TA RGET command displays the elements for a selected row in the Relay
Word bit table (see Appendix A: Relay Word Bits).
TAR
Use the TAR command to view a row of Relay Word bit elements or aliases.
When using the TAR command, you can specify the row number or element
name.
The relay memorizes the latest target row input conditioned by your present
access level. The relay displays Row 0 if you have not specified a row since
power up, the access level has timed out, or you have issued the QUIT
command.
If you specify the repeat count k at a number greater than 8, the relay displays
the repeated target rows on the terminal screen in groups of eight, with the
target row elements listed above each grouping.
Table 9.131 SUM ACK Command
Command Description Access Level
SUM ACK Acknowledge the oldest unacknowledged
event summary at the present communications
port.
1, B, P, A, O, 2
Table 9.132 SUM N Command
Command Description Access Level
SUM N View the oldest unacknowledged event sum-
mary at the present communications port.
1, B, P, A, O, 2
Tabl e 9. 13 3 TA R Comm a nd
Command Description Access Level
TAR Display target Row 0 or display the most
recently viewed target row.
1, B, P, A, O, 2
TAR n Display target Row n. 1, B, P, A, O, 2
TAR n k
a
a
Parameter k is the repeat count from 1–32767.
Display target Row n and repeat for k times;
the repeat count k must follow the row number.
1, B, P, A, O, 2
TAR name Display the target row with the element name
name.
1, B, P, A, O, 2
TAR name k Display the target row with the element name
name and repeat for k times; the repeat count k
can be before or after the name option.
1, B, P, A, O, 2
