Sel SEL-421 - Object 1, 2 Indices 1600-1615 Front-Panel Targets

R.6.23
Date Code 20111215 Reference Manual SEL-421 Relay
DNP3 Communications
DNP3 Documentation
Object 1, 2 indices 1600–1615 represent the front-panel target Relay Word
bits as listed in Table 6.12.
Object 30, Index 176 is a 16-bit composite value, where the upper byte value
indicates an event cause as shown in Table 6.13 and a fault type shown in
Tab le 6.15.
615–608
CCIN025 CCIN026 CCIN027 CCIN028 CCIN029 CCIN030 CCIN031 CCIN032
623–616
CCIN017 CCIN018 CCIN019 CCIN020 CCIN021 CCIN022 CCIN023 CCIN024
631–624
CCIN009 CCIN010 CCIN011 CCIN012 CCIN013 CCIN014 CCIN015 CCIN016
639–632
CCIN001 CCIN002 CCIN003 CCIN004 CCIN005 CCIN006 CCIN007 CCIN008
647–640
CCOUT25 CCOUT26 CCOUT27 CCOUT28 CCOUT29 CCOUT30 CCOUT31 CCOUT32
655–648
CCOUT17 CCOUT18 CCOUT19 CCOUT20 CCOUT21 CCOUT22 CCOUT23 CCOUT24
663–656
CCOUT09 CCOUT10 CCOUT11 CCOUT12 CCOUT13 CCOUT14 CCOUT15 CCOUT16
671–664
CCOUT01 CCOUT02 CCOUT03 CCOUT04 CCOUT05 CCOUT06 CCOUT07 CCOUT08
679–672
CCSTA01 CCSTA02 CCSTA03 CCSTA04 CCSTA05 CCSTA06 CCSTA07 CCSTA08
687–680
CCSTA09 CCSTA10 CCSTA11 CCSTA12 CCSTA13 CCSTA14 CCSTA15 CCSTA16
695–688
CCSTA17 CCSTA18 CCSTA19 CCSTA20 CCSTA21 CCSTA22 CCSTA23 CCSTA24
703–696
CCSTA25 CCSTA26 CCSTA27 CCSTA28 CCSTA29 CCSTA30 CCSTA31 CCSTA32
711–704
FSERP1 FSERP2 FSERP3 FSERPF * * * *
719–712
ALTI ALTV ALTS2 DELAY * * * *
a
An * denotes reserved for future use.
Tabl e 6 . 11 SE L- 42 1 Object 1, 2 Relay Word Bit Mapping (Sheet 3 of 3)
Index Range
Relay Word Bits
a
7 6 5 4 3 2 1 0
Table 6.12 Object 1, 2 Indices 1600—1615 Front-Panel Targets
Index Relay Word Bit Description
1600 TLED_8 Front-panel target 8
1601 TLED_7 Front-panel target 7
1602 TLED_6 Front-panel target 6
1603 TLED_5 Front-panel target 5
1604 TLED_4 Front-panel target 4
1605 TLED_3 Front-panel target 3
1606 TLED_2 Front-panel target 2
1607 TLED_1 Front-panel target 1
1608 TLED_16 Front-panel target 16
1609 TLED_15 Front-panel target 15
1610 TLED_14 Front-panel target 14
1611 TLED_13 Front-panel target 13
1612 TLED_12 Front-panel target 12
1613 TLED_11 Front-panel target 11
1614 TLED_10 Front-panel target 10
1615 TLED_9 Front-panel target 9
