Sel SEL-421 - Global Settings; Global Settings Categories

R.10.4
SEL-421 Relay Reference Manual Date Code 20111215
Settings
Global Settings
=>>SET T <Enter>
Alias
Relay Aliases
(RW Bit or Analog Qty. 7 Character Alias [0-9 A-Z _])
1: EN,"RLY_EN"
? <Enter>
2:
? OUT101, BK1_TR
3:
? END <Enter>
Alias
Relay Aliases
(RW Bit or Analog Qty. 7 Character Alias [0-9 A-Z _])
1: EN,"RLY_EN"
2: OUT101,"BK1_TR"
.
.
.
Save settings (Y,N) ?Y <Enter>
Saving Settings, Please Wait...........
Settings Saved
=>>
Figure 10.1 Changing a Default Name to an Alias
Global Settings
Table 10.1 Default Alias Settings
Label Default Value
EN RLY_EN
Table 10.2 Global Settings Categories
Settings Reference
General Global Settings Table 10.3
Global Enables Table 10.4
Station DC1 Monitor (and Station DC2 Monitor) Table 10.5
Control Inputs (Global) Table 10.6
Main Board Control Inputs Table 10.7
Interface Board #1 Control Inputs Table 10.8
Interface Board #2 Control Inputs Table 10.9
Settings Group Selection Table 10.10
Data Reset Control Table 10.11
Frequency Estimation Table 10.12
Time-Error Calculation Table 10.13
Current and Voltage Source Selection Table 10.14
Synchronized Phasor Measurement Table 10.15
Time and Date Measurement Table 10.16
