Date Code 20111215 Reference Manual SEL-421 Relay
Relay Word Bits
Row List
119 PLT32 Protection Latch 32
119 PLT31 Protection Latch 31
119 PLT30 Protection Latch 30
119 PLT29 Protection Latch 29
119 PLT28 Protection Latch 28
119 PLT27 Protection Latch 27
119 PLT26 Protection Latch 26
119 PLT25 Protection Latch 25
Table A.27 Relay Word Bits: Protection Conditioning Timers (Sheet 1 of 2)
Row Name Description
120 PCT08Q Protection Conditioning Timer 8 output
120 PCT07Q Protection Conditioning Timer 7 output
120 PCT06Q Protection Conditioning Timer 6 output
120 PCT05Q Protection Conditioning Timer 5 output
120 PCT04Q Protection Conditioning Timer 4 output
120 PCT03Q Protection Conditioning Timer 3 output
120 PCT02Q Protection Conditioning Timer 2 output
120 PCT01Q Protection Conditioning Timer 1 output
121 PCT16Q Protection Conditioning Timer 16 output
121 PCT15Q Protection Conditioning Timer 15 output
121 PCT14Q Protection Conditioning Timer 14 output
121 PCT13Q Protection Conditioning Timer 13 output
121 PCT12Q Protection Conditioning Timer 12 output
121 PCT11Q Protection Conditioning Timer 11 output
121 PCT10Q Protection Conditioning Timer 10 output
121 PCT09Q Protection Conditioning Timer 9 output
121 PCT09Q Protection Conditioning Timer 9 output
122 PCT24Q Protection Conditioning Timer 24 output
122 PCT23Q Protection Conditioning Timer 23 output
122 PCT22Q Protection Conditioning Timer 22 output
122 PCT21Q Protection Conditioning Timer 21 output
122 PCT20Q Protection Conditioning Timer 20 output
122 PCT19Q Protection Conditioning Timer 19 output
122 PCT18Q Protection Conditioning Timer 18 output
122 PCT17Q Protection Conditioning Timer 17 output
123 PCT32Q Protection Conditioning Timer 32 output
123 PCT31Q Protection Conditioning Timer 31 output
123 PCT30Q Protection Conditioning Timer 30 output
123 PCT29Q Protection Conditioning Timer 29 output
123 PCT28Q Protection Conditioning Timer 28 output
Table A.26 Relay Word Bits: Protection Latches (Sheet 2 of 2)
Row Name Description
To Next Page
