R.6.21
Date Code 20111215 Reference Manual SEL-421 Relay
DNP3 Communications
DNP3 Documentation
range for each row. To determine the index for a specific point, add the Relay
Word bit number (0 to 7) to the smaller number in the range listed in the first
column. For example, the index of TLED_4 is 12 (the bit number, 4, plus the
smaller number in the range, 8).
Tabl e 6 . 11 SE L- 42 1 Object 1, 2 Relay Word Bit Mapping (Sheet 1 of 3)
Index Range
Relay Word Bits
a
7 6 5 4 3 2 1 0
7–0
EN TRIPLED * * * * * *
15–8
TLED_1 TLED_2 TLED_3 TLED_4 TLED_5 TLED_6 TLED_7 TLED_8
23–16
TLED_9 TLED_10 TLED_11 TLED_12 TLED_13 TLED_14 TLED_15 TLED_16
31–24
3POBK2 3POLINE 3PLSHT BK1RS BK2RS 79CY1 79CY3 BK1LO
39–32
BK2LO BK1CL BK2CL LEADBK0 LEADBK1 LEADBK2 FOLBK0 FOLBK1
47–40
B1OPHA B1OPHB B1OPHC B2OPHA B2OPHB B2OPHC LOPHA LOPHB
55–48
LOPHC SPOA SPOB SPOC SPO 3PO 27APO 27BPO
63–56
27CPO * * * * * * *
71–64
52ACL1 52BCL1 52CCL1 52AAL1 52BAL1 52CAL1 52AA1 52AB1
79–72
52AC1 * 52ACL2 52BCL2 52CCL2 52AAL2 52BAL2 52CAL2
87–80
52AA2 52AB2 52AC2 * * * * *
95–88
* * * * * * * *
103–96
*** * * ***
111–104
* * * * * * * *
119–112
*** * * ***
127–120
BM1TRPA BM1TRPB BM1TRPC BM1CLSA BM1CLSB BM1CLSC B1BCWAL *
135–128
* B1MSOAL B1ESOAL B1PSAL B1PDAL B1BITAL B1MRTAL B1MRTIN
143–136
BM2TRPA BM2TRPB BM2TRPC BM2CLSA BM2CLSB BM2CLSC B2BCWAL *
151–144
* B2MSOAL B2ESOAL B2PSAL B2PDAL B2BITAL B2MRTAL B2MRTIN
159–152
RTD08ST RTD07ST RTD06ST RTD05ST RTD04ST RTD03ST RTD02ST RTD01ST
167–160
RTDIN RTDCOMF RTDFL * RTD12ST RTD11ST RTD10ST RTD09ST
175–168
DC1F DC1W DC1G DC1R DC2F DC2W DC2G DC2R
183–176
PDEM QDEM GDEM * * * * *
191–184
RB25 RB26 RB27 RB28 RB29 RB30 RB31 RB32
199–192
RB17 RB18 RB19 RB20 RB21 RB22 RB23 RB24
207–200
RB09 RB10 RB11 RB12 RB13 RB14 RB15 RB16
215–208
RB01 RB02 RB03 RB04 RB05 RB06 RB07 RB08
223–216
SG6 SG5 SG4 SG3 SG2 SG1 CHSG *
231–224
* IN107 IN106 IN105 IN104 IN103 IN102 IN101
239–232
IN208 IN207 IN206 IN205 IN204 IN203 IN202 IN201
247–240
IN216 IN215 IN214 IN213 IN212 IN211 IN210 IN209
255–248
IN224 IN223 IN222 IN221 IN220 IN219 IN218 IN217
263–256
IN308 IN307 IN306 IN305 IN304 IN303 IN302 IN301
271–264
IN316 IN315 IN314 IN313 IN312 IN311 IN310 IN309
279–272
IN324 IN323 IN322 IN321 IN320 IN319 IN318 IN317
287–280
PSV08 PSV07 PSV06 PSV05 PSV04 PSV03 PSV02 PSV01
