Sel SEL-421 - Application Example Binary Input Map; Application Example Binary Output Map; Application Example Analog Input Map

R.6.52
SEL-421 Relay Reference Manual Date Code 20111215
DNP3 Communications
DNP LAN/WAN Application Example
Table 6.28 DNP LAN/WAN Application Example Binary Input Map
Setting Name Setting Description
BIM0000 Database Address 1:STATE:ELEMENTS:0 SER Point 1 (EN)
BIM0001 Database Address 1:STATE:ELEMENTS:1 SER Point 2 (TRIPLED)
BIM0002 Database Address 1:STATE:ELEMENTS:2 SER Point 3 (IN101)
BIM0003 Database Address 1:STATE:ELEMENTS:3 SER Point 4 (IN102)
BIM0004 Database Address 1:STATE:ELEMENTS:4 SER Point 5 (IN103)
BIM0005 Database Address 1:STATE:ELEMENTS:5 SER Point 6 (IN104)
BIM0006 Database Address 1:STATE:ELEMENTS:6 SER Point 7 (SALARM)
BIM0007 Database Address 1:STATE:ELEMENTS:7 SER Point 8 (HALARM)
BIM0008 Database Address 1:STATE:ELEMENTS:8 SER Point 9 (TESTDNP)
Table 6.29 DNP LAN/WAN Application Example Binary Output Map
Setting Name Setting Description
BOM0000 Database Address 128 Custom BO map position for RB01 Control
BOM0001 Database Address 129 Custom BO map position for RB02 Control
BOM0002 Database Address 130 Custom BO map position for RB03 Control
BOM0003 Database Address 131 Custom BO map position for RB04 Control
BOM0004 Database Address 132 Custom BO map position for RB05 Control
BOM0005 Database Address 133 Custom BO map position for RB06 Control
BOM0006 Database Address 176 Custom BO map position for
Circuit Breaker 1 trip/close Control
Table 6.30 DNP LAN/WAN Application Example Analog Input Map (Sheet 1 of 2)
Setting Name Point
Scale
Fact or
Deadband Description
AIM0000
Database Address
1:METER:IA1 (Meter
Region IA1)
1 50 Custom map position for IA1 magnitude, scale by 10 and
report 5 amp change events
AIM0001
Database Address
1:100Ch Custom map position for IA1 angle
a
, scale by 100 and
report 2 degree change events
AIM0002
Database Address
1:METER:IB1 (Meter
Region IB1)
1 50 Custom map position for IB1 magnitude
a
, scale by 10
and report 5 amp change events
AIM0003
Database Address
1:1010h Custom map position for IB1 angle
a
, scale by 100 and
report 2 degree change events
AIM0004
Database Address
1:METER:IC1 (Meter
Region IC1)
1 50 Custom map position for IC1 magnitude
a
, scale by 10
and report 5 amp change events
AIM0005
Database Address
1:1014h Custom map position for IC1 angle
a
, scale by 100 and
report 2 degree change events
AIM0006
Database Address
1:METER:VA (Meter
Region VA )
1 10000 Custom map position for VA magnitude, scale by 10 and
report 1 kv change events
AIM0007
Database Address
1:103Ch Custom map position for VA angle
a
, scale by 100 and
report 2 degree change events
AIM0008
Database Address
1:METER:VB (Meter
Region VB)
1 10000 Custom map position for VB magnitude, scale by 10 and
report 1 kv change events
AIM0009
Database Address
1:1040h Custom map position for VB angle
a
, scale by 100 and
report 2 degree change events
AIM0010
Database Address
1:METER:VC (Meter
Region VC)
1 10000 Custom map position for VC magnitude, scale by 10 and
report 1 kv change events
