Date Code 20111215 Reference Manual SEL-421 Relay
ASCII Command Reference
Description of Commands
CHI
Use the CHI command to gather one-line descriptions of event reports.
CHI TERSE
The CHI TERSE command returns a Compressed ASCII event report
without the event report label lines.
CLOSE n
Use the CLOSE n command to close a circuit breaker. The main board circuit
breaker jumper (on connector J18C) must be in place. Further, you must set
relay setting NUMBK := 2 to issue a CLOSE 2 command.
The CLOSE 1 and CLOSE 2 commands assert Relay Word bits CC1 and
CC2, respectively. Relay Word bit CC1 is a variable in the factory default
manual close SEL equation BK1MCL Circuit Breaker 1. Typically, you
program Relay Word bit CC2 in the manual close SEL
OGIC control equation
BK2MCL for Circuit Breaker 2. The relay uses these equations and additional
relay logic to assert a control output (for example, OUT103 := BK1CL) to
close a circuit breaker. See Control Outputs on page U.2.7, and Section 2:
Auto-Reclosing and Synchronism Check for more information.
If the circuit breaker control enable jumper J18C is in place, the relay
responds,
Close breaker (Y/N)? When you answer Y <Enter> (for yes), the
relay prompts,
Are you sure (Y/N)? If you again answer Y <Enter>, the
relay asserts the Relay Word bit for one processing interval.
Tabl e 9. 26 CHI Co mma n d
Command Description Access Level
CHI Return the data as contained in the History
report for the most recent 100 event reports in
Compressed ASCII format (for SEL-2030
compatibility).
1, B, P, A, O, 2
CHI A Return one-line descriptions of the most recent
100 event reports in Compressed ASCII for-
mat.
1, B, P, A, O, 2
CHI k Return one-line descriptions of the most recent
k number of event reports in Compressed
ASCII format.
1, B, P, A, O, 2
Tabl e 9. 27 CHI TER S E Comma nd
Command Description Access Level
CHI TERSE Return one-line descriptions for the most
recent 100 event reports without the label lines
in Compressed ASCII format.
1, B, P, A, O, 2
CHI k TERSE Return one-line descriptions for the most
recent k number of event reports without the
label lines in Compressed ASCII format.
1, B, P, A, O, 2
Tabl e 9. 28 CLOSE n Co mma n d
Command Description Access Level
CLOSE 1 Command the relay to close Circuit Breaker 1. B, P, A, O, 2
CLOSE 2 Command the relay to close Circuit Breaker 2
(if NUMBK := 2).
B, P, A, O, 2
