Synchrophasors
C37.118 Synchrophasor Protocol
This method of data capture will always report from the exact second, even if
the time parameter is entered with fractional seconds. For example, entering
MET PM 14:14:12.200 will result in the same data capture as MET PM
14:14:12, because the relay ignores the fractional seconds.
See MET PM on page R.9.31 for complete command options, and error
messages.
=>MET PM <Enter>
Relay 1 Date: 10/26/2004 Time: 19:18:23.000
Station A Serial Number: 0000000000
Time Quality Maximum time synchronization error: 0.000 (ms) TSOK = 1
Synchrophasors
Phase Voltages Pos. Sequence Voltage
VA VB VC V1
MAG (kV) 134.140 131.646 128.600 131.447
ANG (DEG) 129.896 10.262 -111.764 129.477
IW Phase Currents IW Pos. Sequence Current
IA IB IC I1W
MAG (kV) 365.261 359.225 379.917 367.912
ANG (DEG) 114.930 -2.786 -120.238 117.338
IX Phase Currents IX Pos. Sequence Current
IA IB IC I1X
MAG (kV) 617.050 587.237 599.044 600.935
ANG (DEG) 136.345 13.617 -106.733 134.434
IS Phase Currents IS Pos. Sequence Current
IA IB IC I1S
MAG (kV) 966.340 937.347 972.512 958.708
ANG (DEG) 128.412 7.404 -111.967 127.955
FREQ (Hz) 60.029
Rate-of-change of FREQ (Hz/s) 0.00
Digitals
PSV40 PSV39 PSV38 PSV37 PSV36 PSV35 PSV34 PSV33
0 0 0 0 0 0 0 0
PSV48 PSV47 PSV46 PSV45 PSV44 PSV43 PSV42 PSV41
0 0 0 0 0 0 0 0
PSV56 PSV55 PSV54 PSV53 PSV52 PSV51 PSV50 PSV49
0 0 0 0 0 0 0 0
PSV64 PSV63 PSV62 PSV61 PSV60 PSV59 PSV58 PSV57
1 0 1 0 0 0 0 0
Analogs
PMV57 0.000 PMV58 0.000 PMV59 0.000 PMV60 0.000
PMV61 0.000 PMV62 0.000 PMV63 127.000 PMV64 23.400
=>
Figure 7.13 Sample MET PM Command Response
C37.118 Synchrophasor Protocol
The SEL-421 complies with IEEE C37.118, Standard for Synchrophasors for
Power Systems, when Global setting MFRMT := C37.118.
The protocol is available on serial ports 1, 2, 3, and F by setting the
corresponding Port setting PROTO := PMU.
The protocol is available on the Ethernet port when EPMIP := Y.
This subsection does not cover the details of the protocol, but highlights some
of the important features and options that are available.
