Relay Word Bits
Row List
96 CHSG Settings Group Change
96 * Reserved
97–99 * Reserved
Table A.24 Relay Word Bits: Input Elements (Sheet 1 of 2)
Row Name Description
100 * Reserved
100 IN107 Main Board Input 7
100 IN106 Main Board Input 6
100 IN105 Main Board Input 5
100 IN104 Main Board Input 4
100 IN103 Main Board Input 3
100 IN102 Main Board Input 2
100 IN101 Main Board Input 1
101 IN208 First Optional I/O Board Input 8 (if installed)
101 IN207 First Optional I/O Board Input 7 (if installed)
101 IN206 First Optional I/O Board Input 6 (if installed)
101 IN205 First Optional I/O Board Input 5 (if installed)
101 IN204 First Optional I/O Board Input 4 (if installed)
101 IN203 First Optional I/O Board Input 3 (if installed)
101 IN202 First Optional I/O Board Input 2 (if installed)
101 IN201 First Optional I/O Board Input 1 (if installed)
102 IN216 First Optional I/O Board Input 16 (if installed)
102 IN215 First Optional I/O Board Input 15 (if installed)
102 IN214 First Optional I/O Board Input 14 (if installed)
102 IN213 First Optional I/O Board Input 13 (if installed)
102 IN212 First Optional I/O Board Input 12 (if installed)
102 IN211 First Optional I/O Board Input 11 (if installed)
102 IN210 First Optional I/O Board Input 10 (if installed)
102 IN209 First Optional I/O Board Input 9 (if installed)
103 IN224 First Optional I/O Board Input 24 (if installed)
103 IN223 First Optional I/O Board Input 23 (if installed)
103 IN222 First Optional I/O Board Input 22 (if installed)
103 IN221 First Optional I/O Board Input 21 (if installed)
103 IN220 First Optional I/O Board Input 20 (if installed)
103 IN219 First Optional I/O Board Input 19 (if installed)
103 IN218 First Optional I/O Board Input 18 (if installed)
103 IN217 First Optional I/O Board Input 17 (if installed)
104 IN308 Second Optional I/O Board Input 8 (if installed)
104 IN307 Second Optional I/O Board Input 7 (if installed)
104 IN306 Second Optional I/O Board Input 6 (if installed)
Table A.23 Relay Word Bits: Active Protection Settings Group (Sheet 2 of 2)
Row Name Description
