Sel SEL-421 - Interface Board #1; Interface Board #2; Communications Card Outputs

R.10.36
SEL-421 Relay Reference Manual Date Code 20111215
Settings
Output Settings
Make Table 10.74 settings if interface board #1 is present.
Make Table 10.75 settings if interface board #2 is present.
Make Table 10.76 settings if a communications card is present.
OUT105 NA
OUT106 NA
OUT107 PLT04 #RELAY TEST MODE
OUT108 NOT (SALARM OR HALARM)
Table 10.74 Interface Board #1
Label Prompt Default Value
OUT201 NA
•
•
•
•
•
•
•
•
•
OUT216 NA
Table 10.75 Interface Board #2
Label Prompt Default Value
OUT301 NA
•
•
•
•
•
•
•
•
•
OUT316 NA
Table 10.76 Communications Card Outputs
Label Prompt Default Value
CCOUT01 NA
•
•
•
•
•
•
•
•
•
CCOUT32 NA
Table 10.73 Main Board (Sheet 2 of 2)
Label Prompt Default Value
NOTE: See corresponding command
descriptions SET O on page R.9.42
and SHO O on page R.9.46 to set or
show the Output settings.
