R.9.20
SEL-421 Relay Reference Manual Date Code 20111215
ASCII Command Reference
Description of Commands
EVE NEXT
EVE NEXT returns the oldest unacknowledged event report on the present
communications port.
EVE NSET
The EVE NSET command returns the event report with no relay settings.
EVE NSUM
The EVE NSUM returns the event report with no event summary.
EVE Sx
Use the EVE Sx command to specify the sample data resolution of the event
report. The sample data resolution x is either 4 samples/cycle or 8 samples/
cycle; the default value is 4 samples/cycle if you do not specify Sx. The Sx
option overrides the L option.
Table 9.54 EVE N Command
Command Description Access Level
EVE N Return the oldest unacknowledged event report
with 4-samples/cycle data.
1, B, P, A, O, 2
Table 9.55 EVE NSET Command
Command Description Access Level
EVE NSET Return the most recent event report without
settings at full length with 4-samples/cycle
data.
1, B, P, A, O, 2
EVE n NSET
a
a
Parameter n indicates event order or serial number; see EVE on page R.9.17.
Return a particular n event report without set-
tings at full length with 4-samples/cycle data.
1, B, P, A, O, 2
Tabl e 9. 56 EVE NSU M Co mma n d
Command Description Access Level
EVE NSUM Return the most recent event report without the
event summary at full length with 4-samples/
cycle data.
1, B, P, A, O, 2
EVE n NSUM
a
a
Parameter n indicates event order or serial number; see EVE on page R.9.17.
Return a particular n event report without the
event summary at full length with 4-samples/
cycle data.
1, B, P, A, O, 2
Table 9.57 EVE Sx Command
Command Description Access Level
EVE Sx Return the most recent event report at full
length with x-samples/cycle data.
1, B, P, A, O, 2
EVE n Sx
a
a
Parameter n indicates event order or serial number (see EVE on page R.9.17); x is 4 or 8 to
represent data at 4 samples/cycle or 8 samples/cycle, respectively.
Return a particular n event report at full length
with x-samples/cycle data.
1, B, P, A, O, 2
