R.9.19
Date Code 20111215 Reference Manual SEL-421 Relay
ASCII Command Reference
Description of Commands
EVE D
Use EVE D to return only the digital information in the event report.
EVE L
Use EVE L to return a large resolution (8-samples/cycle) event report. The Sx
option overrides the L option (see EVE Sx).
EVE Lyyy
Command EVE Lyyy returns a specified length event report, where Lyyy
indicates a length of yyy cycles. You can specify yyy from 1 cycle up to a value
including and exceeding the event report total cycle length. If yyy is longer
than the total length, the relay returns the full duration event report. The Lyyy
option overrides the C option.
Table 9.50 EVE C Command
Command Description Access Level
EVE C Return the most recent event report at a
15-cycle length with 8-samples/cycle data.
1, B, P, A, O, 2
EVE C n
a
a
Parameter n indicates event order or serial number; see EVE on page R.9.17.
Return a particular n event report at a 15-cycle
length with 8-samples/cycle data.
1, B, P, A, O, 2
Table 9.51 EVE D Command
Command Description Access Level
EVE D Return only the digital information for the
most recent event report with 4-samples/cycle
data.
1, B, P, A, O, 2
EVE D n
a
a
Parameter n indicates event order or serial number (see EVE on page R.9.17).
Return only the digital information for a partic-
ular n event report with 4-samples/cycle data.
1, B, P, A, O, 2
Table 9.52 EVE L Command
Command Description Access Level
EVE L Return the most recent event report at full
length with 8-samples/cycle data.
1, B, P, A, O, 2
EVE n L
a
a
Parameter n indicates event order or serial number (see EVE on page R.9.17).
Return a particular n event report at full length
with 8-samples/cycle data.
1, B, P, A, O, 2
Tabl e 9. 53 EV E Lyy y Co mma n d
Command Description Access Level
EVE Lyyy Return yyy cycles of the most recent event
report (including settings) with 4-samples/
cycle data.
1, B, P, A, O, 2
EVE n Lyyy
a
a
Parameter n indicates event order or serial number; see EVE on page R.9.17.
Return yyy cycles of a particular n event report
with 4-samples/cycle data.
1, B, P, A, O, 2
