R.6.41
Date Code 20111215 Reference Manual SEL-421 Relay
DNP3 Communications
DNP LAN/WAN Documentation
Summary and detailed map configurations are also available in the
DNPMAP.TXT and DNPMAPnn.TXT files from the SEL-421 FTP interface.
The individual file names associated with the detailed custom map settings
follow the DNPMAPnn.TXT naming convention.
Testing
Use the TEST DB command to test the communications card relay database.
The TEST DB command can be used to override any value in the relay
database. Since the relay database provides data to the communications card
interfaces, the TEST DB command can also be used to test the data read
operations of any of the protocols on an installed Ethernet card. Use the
MAP 1 command and the VIEW 1 command to inspect the relay database
(see MAP on page R.9.27). You must be familiar with the relay database
structure to use the TEST DB command effectively; see Communications
Card Database on page R.4.18 for more information.
DNP LAN/WAN Documentation
The following section contains information specific to the DNP3 LAN/WAN
implementation.
Device Profile
Tab le 6.23 contains the standard DNP LAN/WAN device profile information.
Rather than checkboxes in the example Device Profile in the DNP3 Subset
Definitions, only the relevant selections are shown.
Table 6.23 SEL-421 DNP LAN/WAN Device Profile (Sheet 1 of 2)
Parameter Value
Vendor name Schweitzer Engineering Laboratories
Device name SEL-421 Relay with Ethernet card
Highest DNP request level Level 2
Highest DNP response level Level 2
Device function Slave
Notable objects, functions, and/or
qualifiers supported
None
Maximum data link frame size transmitted/
received (octets)
292
Maximum data link retries 0
Requires data link layer confirmation No
Maximum application fragment size
transmitted/received (octets)
2048
Maximum application layer retries None
Requires application layer confirmation When reporting Event Data
Data link confirm time-out Configurable
Complete application fragment time-out None
Application confirm time-out Configurable
Complete Application response time-out None
Executes control WRITE binary outputs Always
Executes control SELECT/OPERATE Always
Executes control DIRECT OPERATE Always
