R.A.80
SEL-421 Relay Reference Manual Date Code 20111215
Relay Word Bits
Row List
293 RTCAD16 RTC Remote Data Bits, Channel A, bit 16
293 RTCAD15 RTC Remote Data Bits, Channel A, bit 15
293 RTCAD14 RTC Remote Data Bits, Channel A, bit 14
293 RTCAD13 RTC Remote Data Bits, Channel A, bit 13
293 RTCAD12 RTC Remote Data Bits, Channel A, bit 12
293 RTCAD11 RTC Remote Data Bits, Channel A, bit 11
293 RTCAD10 RTC Remote Data Bits, Channel A, bit 10
293 RTCAD09 RTC Remote Data Bits, Channel A, bit 9
294 RTCBD08 RTC Remote Data Bits, Channel B, bit 8
294 RTCBD07 RTC Remote Data Bits, Channel B, bit 7
294 RTCBD06 RTC Remote Data Bits, Channel B, bit 6
294 RTCBD05 RTC Remote Data Bits, Channel B, bit 5
294 RTCBD04 RTC Remote Data Bits, Channel B, bit 4
294 RTCBD03 RTC Remote Data Bits, Channel B, bit 3
294 RTCBD02 RTC Remote Data Bits, Channel B, bit 2
294 RTCBD01 RTC Remote Data Bits, Channel B, bit 1
295 RTCBD16 RTC Remote Data Bits, Channel B, bit 16
295 RTCBD15 RTC Remote Data Bits, Channel B, bit 15
295 RTCBD14 RTC Remote Data Bits, Channel B, bit 14
295 RTCBD13 RTC Remote Data Bits, Channel B, bit 13
295 RTCBD12 RTC Remote Data Bits, Channel B, bit 12
295 RTCBD11 RTC Remote Data Bits, Channel B, bit 11
295 RTCBD10 RTC Remote Data Bits, Channel B, bit 10
295 RTCBD09 RTC Remote Data Bits, Channel B, bit 9
Table A.55 Fast Operate Transmit Bits (Sheet 1 of 4)
Row Bit Name Description
296 FOPF_08 Fast Operate Output Control Bits for Port F, bit 8
296 FOPF_07 Fast Operate Output Control Bits for Port F, bit 7
296 FOPF_06 Fast Operate Output Control Bits for Port F, bit 6
296 FOPF_05 Fast Operate Output Control Bits for Port F, bit 5
296 FOPF_04 Fast Operate Output Control Bits for Port F, bit 4
296 FOPF_03 Fast Operate Output Control Bits for Port F, bit 3
296 FOPF_02 Fast Operate Output Control Bits for Port F, bit 2
296 FOPF_01 Fast Operate Output Control Bits for Port F, bit 1
297 FOPF_16 Fast Operate Output Control Bits for Port F, bit 16
297 FOPF_15 Fast Operate Output Control Bits for Port F, bit 15
297 FOPF_14 Fast Operate Output Control Bits for Port F, bit 14
297 FOPF_13 Fast Operate Output Control Bits for Port F, bit 13
297 FOPF_12 Fast Operate Output Control Bits for Port F, bit 12
297 FOPF_11 Fast Operate Output Control Bits for Port F, bit 11
Tabl e A . 54 RTC Re mot e Dig ita l St a tus (Sheet 2 of 2)
Row Bit Name Description
