R.6.50
SEL-421 Relay Reference Manual Date Code 20111215
DNP3 Communications
DNP LAN/WAN Application Example
Settings
Use the ACSELERATOR QuickSet
®
SEL-5030 software to enter the DNP3
protocol settings and new data map into the relay.
Table 6.26 DNP LAN/WAN Application Example Custom Data Map
Name Object Type
Custom
Map
Index
Description
EN Binary Input 0 Relay enabled
TRIPLED Binary Input 1
IN101 Binary Input 2
IN102 Binary Input 3
IN103 Binary Input 4
IN104 Binary Input 5
SALARM Binary Input 6
HALARM Binary Input 7
TESTDNP Binary Input 8
RB01 Binary Output 0 General use Control Point (Remote Bit) 1
RB02 Binary Output 1 General use Control Point (Remote Bit) 2
RB03 Binary Output 2 General use Control Point (Remote Bit) 3
RB04 Binary Output 3 General use Control Point (Remote Bit) 4
RB05 Binary Output 4 General use Control Point (Remote Bit) 5
RB06 Binary Output 5 General use Control Point (Remote Bit) 6
OC1, CC1 Binary Output 6 Circuit Breaker 1 trip/close
Table 6.27 DNP LAN/WAN Application Example Protocol Settings
(Sheet 1 of 2)
Setting Name Setting Description
ENDNP Y Enable DNP3
DNPADR 101 DNP3 Address for Relay is 101
DNPPNUM 20000
a
DNP3 Port Number for TCP
DNPMAP CUSTOM CUSTOM DNP3 map Mode
ECLASSA 1 Analog Event Data = Class 1
ECLASSB 1 Binary Event Data = Class 1
ECLASSC 1 Counter Event Data = Class 1
DECPL 2 Scale analog data, multiplying by 10 to send whole
numbers and tenths. The relay would report a value of
5.25 as 525, which would remain unscaled at the
master. (102=100)
ANADB 200 Analog Deadband Counts, set to 2 engineering units,
based on DECPL scaling factor
STIMEO 1.0
a
1.0 Second to Select/Operate Time-out
DNPPAIR N
a
AUTO Mode: Disable Use of DNP3 Trip Close Pairs
DNPINA 120
a
Wait 120 Seconds to send Inactive Heartbeat
NUMEVE 10
a
Transmit after 10 Events
AGEEVE 2
a
Transmit when Age of Oldest Event = 2 sec
ETIMEO 2
a
Event Message Confirm Timeout (2 sec)
