R.9.46
SEL-421 Relay Reference Manual Date Code 20111215
ASCII Command Reference
Description of Commands
SHO L
Use the SHO L command to show the Protection SELOGIC control equations.
See Section 3: SEL
OGIC Control Equation Programming for more information
on SEL
OGIC control equations.
SHO M
Use the SHO M command to show the circuit breaker monitor settings. There
is only one instance for the Breaker Monitor class. See Section 2: Monitoring
and Metering in the Applications Handbook for information on the circuit
breaker monitor.
SHO O
Use the SHO O command to show the Output SELOGIC control equations.
See Control Outputs on page U.2.7 for more information on relay control
outputs.
Table 9.117 SHO G Command
Command Description Access Level
SHO G Show the Global relay settings, beginning at
the first setting in this class.
1, B, P, A, O, 2
SHO G label Show the Global relay settings, beginning at
the settings label label.
1, B, P, A, O, 2
Table 9.118 SHO L Command
Command Description Access Level
SHO L Show the Protection SELOGIC control equation
relay settings for the active group.
1, B, P, A, O, 2
SHO L n
a
a
Parameter n is 1–6 for Group 1 through Group 6.
Show the Protection SELOGIC control equation
relay settings for Instance n, which is Group n.
1, B, P, A, O, 2
Table 9.119 SHO M Command
Command Description Access Level
SHO M Show the Breaker Monitor relay settings,
beginning at the first setting in this class.
1, B, P, A, O, 2
SHO M label Show the Breaker Monitor relay settings,
beginning at the settings label label.
1, B, P, A, O, 2
Table 9.120 SHO O Command
Command Description Access Level
SHO O Show the Output SELOGIC control equation
relay settings, beginning at OUT101.
1, B, P, A, O, 2
SHO O label Show the Output SEL
OGIC control equation
relay settings, beginning at the output label
label.
1, B, P, A, O, 2
