R.9.58
SEL-421 Relay Reference Manual Date Code 20111215
ASCII Command Reference
Description of Commands
A sample VER command response is shown in Figure 9.3:
=>VER <Enter>
FID=SEL-421-R101-V0-Z001001-D20010315
CID=5EEA
Part Number: 04210415X11XXHX
Serial Number: 2001001234
SELboot:
BFID= SLBT-4XX-R1XX-V0-Z001001-D20010703
Checksum: D507
Mainboard:
Code FLASH Size: 4 MB
Data FLASH Size: 8 MB
RAM Size: 2 MB
EEPROM Size: 64 kB
Front Panel: installed
Analog Inputs:
W: Currents: 5 Amp
X: Currents: 5 Amp
Y: Voltage: 67 Volts
Z: Voltage: 67 Volts
Fiber Port: not installed
Interface Boards:
Board 1: not installed
Board 2: not installed
Communications Card:
not installed
Extended Relay Features:
None
If the information above is not as expected, contact SEL for assistance.
=>
Figure 9.3 Sample VER Command Response
If an item is not installed, the VER report indicates Not installed at the
appropriate line. If a detected hardware configuration does not match the
component part number, the relay adds the statement
Warning - hardware
does not match part number
on the corresponding line.
VIEW
Use the VIEW command to examine data within the relay database. You can
view these data in three ways:
➤ Region
➤ Register item
➤ Bit
The VIEW command in the SEL-421 is very similar to the VIEW command
in SEL Communications Processors. See Section 4: Communications
Interfaces for more information on the relay database regions and data types.
SEL-421 regions are LOCAL, METER, DEMAND, TARGET, HISTORY,
BREAKER, STATUS, and ANALOGS; view this list with the MAP 1
command.
The SEL-421 is Virtual Device 1; all commands begin VIEW 1. In all
database views, if a data item is in test mode, the relay displays an asterisk (*)
mark following the data value.
