R.9.5
Date Code 20111215 Reference Manual SEL-421 Relay
ASCII Command Reference
Description of Commands
CBR TERSE
The CBR TERSE command omits the breaker report labels.
CEVENT
The CEVENT command provides a Compressed ASCII response similar to
the EVENT command. See Section 5: SEL Communications Protocols for
information on the Compressed ASCII command set. For detailed examples of
the items in the Compressed ASCII event report, see CEVENT on
page A.3.24.
CEV
Use the CEV command to gather relay event reports. When parameter n is 1
through 9999, n indicates the order of the event report. The most recent event
report is 1, the next most recent report is 2, and so on. When parameter n is
10000 through 42767, n indicates the absolute serial number of the event
report.
CEV ACK
Use CEV ACK to acknowledge viewing the oldest unacknowledged event on
the present communications port. View this event with the CEV NEXT or
EVE NEXT commands.
Table 9.14 CBR TERSE Command
Command Description Access Level
CBR TERSE Return the most recent circuit breaker report
for Circuit Breaker 1 and Circuit Breaker 2 in
Compressed ASCII format; suppress the
labels; transmit only the data lines.
1, B, P, A, O, 2
CBR n TERSE
a
a
Parameter n = 1 or 2 to represent Circuit Breaker 1 and Circuit Breaker 2.
Return the most recent circuit breaker report
for Circuit Breaker
n in Compressed ASCII
format; suppress the labels; transmit only the
data lines.
1, B, P, A, O, 2
Table 9.15 CEV Command
Command Description Access Level
CEV Return the most recent event report (including
settings and summary) at full length with
4-samples/cycle data in Compressed ASCII
format.
1, B, P, A, O, 2
CEV n
a
a
Parameter n indicates event order or serial number.
Return particular n event report (including set-
tings and summary) at full length with 4-sam-
ples/cycle data in Compressed ASCII format.
1, B, P, A, O, 2
Tabl e 9. 16 CEV ACK Co m man d
Command Description Access Level
CEV ACK Acknowledge the oldest unacknowledged
event at the present communications port.
1, B, P, A, O, 2
