R.10.6
SEL-421 Relay Reference Manual Date Code 20111215
Settings
Global Settings
Make Table 10.6 settings when Global enable setting EICIS := N.
Make Table 10.7 settings when Global enable setting EICIS := Y.
Table 10.6 Control Inputs
Label Prompt Default Value
GINP
a
a
Setting applies to all direct coupled contact inputs if available, otherwise, the setting is not
available.
Input Pickup Level (15–265 Vdc) 85
b
b
Factory set at 18 for 24/48 Vdc nominal power supply, 36 for 48/125 Vdc nominal power
supply, and 85 for 125/240 Vdc power supply. See Control Inputs on page U.2.5 for setting
guidelines.
GINDF
a,c
c
Setting applies to all direct coupled contact inputs independent of EICIS set to Y or N.
Input Dropout Level (10–100% of pickup level) 80
IN1XXD
d
d
Setting applies to all the main board input contacts.
Main Board Debounce Time (0.0000–5 cyc) 0.1250
IN2XXD
e
e
Setting applies to all the Interface Board #1 input contacts.
Int Board #1 Debounce Time (0.0000–5 cyc
f
)
f
If the interface board has more than eight input contacts, the upper range is 1 cycle.
0.1250
IN3XXD
g
g
Setting applies to all the Interface Board #2 input contacts.
Int Board #2 Debounce Time (0.0000–5 cyc
f
) 0.1250
Table 10.7 Main Board Control Inputs
Label Prompt Default Value
IN101P
a
a
Setting is not available for Main Board B. Set to Global setting GINP when EICIS := N.
Input IN101 Pickup Level (15–265 Vdc) 85
b
b
Factory set at 18 for 24/48 Vdc nominal power supply, 36 for 48/125 Vdc nominal power
supply, and 85 for 125/240 Vdc power supply. See Control Inputs on page U.2.5 for setting
guidelines.
•
•
•
•
•
•
•
•
•
IN107P
a
Input IN107 Pickup Level (15–265 Vdc) 85
b
IN101PU Input IN101 Pickup Delay (0.0000–5 cyc) 0.1250
c
c
Set to Global setting IN1XXD when EICIS := N.
IN101DO Input IN101 Dropout Delay (0.0000–5 cyc) 0.1250
c
•
•
•
•
•
•
•
•
•
IN107PU Input IN107 Pickup Delay (0.0000–5 cyc) 0.1250
c
IN107DO Input IN107 Dropout Delay (0.0000–5 cyc) 0.1250
c
NOTE: Main Board A I/O, INT1, INT5,
and INT6 I/O interface boards have
direct coupled contact inputs. Main
Board B I/O, INT2, INT4, INT7, and
INT8 I/O interface boards have
optoisolated contact inputs. SEL-421-0
and SEL-421-1 do not support Main
Board B I/O, INT2, INT7, and INT8 I/O
interface boards. SEL-421-2 and
SEL-421-3 support all the boards.
NOTE: Main Board A I/O, INT1, INT5,
and INT6 I/O interface boards have
direct coupled contact inputs. Main
Board B I/O, INT2, INT4, INT7, and
INT8 I/O interface boards have
optoisolated contact inputs. SEL-421-0
and SEL-421-1 do not support Main
Board B I/O, INT2, INT7, and INT8 I/O
interface boards. SEL-421-2 and
SEL-421-3 support all the boards.
