Sel SEL-421 - ICD Logical Nodes Summary

R.8.14
SEL-421 Relay Reference Manual Date Code 20111215
IEC 61850 Communications
IEC 61850 Configuration
Table 8.7 ICD Logical Nodes Summary (Sheet 1 of 3)
Logical
Device
Logical Nodes by ICD Version
Description
Ver 001
Ver 002L
Ver 002 Ver 002 R123+
PRO M1PPDIS1 M1PPDIS1 M1PPDIS1 Zone 1 Mho phase element
PRO Z1GPDIS2 Z1GPDIS2 Z1GPDIS2 Zone 1 ground distance element
PRO M2PPDIS3 M2PPDIS3 M2PPDIS3 Zone 2 Mho phase element
PRO Z2GPDIS4 Z2GPDIS4 Z2GPDIS4 Zone 2 ground distance element
PRO M3PPDIS5 M3PPDIS5 M3PPDIS5 Zone 3 Mho phase element
PRO Z3GPDIS6 Z3GPDIS6 Z3GPDIS6 Zone 3 ground distance element
PRO M4PPDIS7 M4PPDIS7 M4PPDIS7 Zone 4 Mho phase element
PRO Z4GPDIS8 Z4GPDIS8 Z4GPDIS8 Zone 4 ground distance element
PRO M5PPDIS9 M5PPDIS9 M5PPDIS9 Zone 5 Mho phase element
PRO Z5GPDIS10 Z5GPDIS10 Z5GPDIS10 Zone 5 ground distance element
PRO P1PIOC1 P1PIOC1 P1PIOC1 Level 1 phase overcurrent element
PRO G1PIOC2 G1PIOC2 G1PIOC2 Level 1 residual overcurrent element
PRO Q1PIOC3 Q1PIOC3 Q1PIOC3 Level 1 negative-sequence overcurrent element
PRO P2PIOC4 P2PIOC4 P2PIOC4 Level 2 phase overcurrent element
PRO G2PIOC5 G2PIOC5 G2PIOC5 Level 2 residual overcurrent element
PRO Q2PIOC6 Q2PIOC6 Q2PIOC6 Level 2 negative-sequence overcurrent element
PRO P3PIOC7 P3PIOC7 P3PIOC7 Level 3 phase overcurrent element
PRO G3PIOC8 G3PIOC8 G3PIOC8 Level 3 residual overcurrent element
PRO Q3PIOC9 Q3PIOC9 Q3PIOC9 Level 3 negative-sequence overcurrent element
PRO G4PIOC10 G4PIOC10 G4PIOC10 Level 4 residual overcurrent element
PRO Q4PIOC11 Q4PIOC11 Q4PIOC11 Level 4 negative-sequence overcurrent element
PRO - - P4PIOC12 Level 4 phase overcurrent element
(missing in previous versions)
PRO P1PTOC1 P1PTOC1 P1PTOC1 Level 1 phase directional overcurrent element
PRO G1PTOC2 G1PTOC2 G1PTOC2 Level 1 residual directional overcurrent element
PRO Q1PTOC3 Q1PTOC3 Q1PTOC3 Level 1 negative-sequence directional overcurrent element
PRO P2PTOC4 P2PTOC4 P2PTOC4 Level 2 phase directional overcurrent element
PRO G2PTOC5 G2PTOC5 G2PTOC5 Level 2 residual directional overcurrent element
PRO Q2PTOC6 Q2PTOC6 Q2PTOC6 Level 2 negative-sequence directional overcurrent element
PRO P3PTOC7 P3PTOC7 P3PTOC7 Level 3 phase directional overcurrent element
PRO G3PTOC8 G3PTOC8 G3PTOC8 Level 3 residual directional overcurrent element
PRO Q3PTOC9 Q3PTOC9 Q3PTOC9 Level 3 negative-sequence directional overcurrent element
PRO P4PTOC10 P4PTOC10 P4PTOC10 Level 4 phase directional overcurrent element
PRO G4PTOC11 G4PTOC11 G4PTOC11 Level 4 residual directional overcurrent element
PRO Q4PTOC12 Q4PTOC12 Q4PTOC12 Level 4 negative-sequence directional overcurrent element
PRO S1PTOC13 S1PTOC13 S1PTOC13 Inverse-Time Overcurrent Element 1 pickup
PRO S2PTOC14 S2PTOC14 S2PTOC14 Inverse-Time Overcurrent Element 2 pickup
PRO S3PTOC15 S3PTOC15 S3PTOC15 Inverse-Time Overcurrent Element 3 pickup
PRO POTTPSCH1 POTTPSCH1 POTTPSCH1 POTT Scheme
