R.8.15
Date Code 20111215 Reference Manual SEL-421 Relay
IEC 61850 Communications
IEC 61850 Configuration
PRO DCBPSCH2 DCBPSCH2 DCBPSCH2 DCB Trip Scheme
PRO DCUBPSCH3 DCUBPSCH3 DCUBPSCH3 DCUB Trip Scheme
PRO TRIPPTRC1 TRIPPTRC1 TRIPPTRC1 Trip status
PRO BK1TRPPTRC2 BKR1PTRC2
a
BKR1PTRC2 Breaker 1 Trip Status
PRO BK2TRPPTRC3 BKR2PTRC2
a
BKR2PTRC2 Breaker 2 Trip Status
PRO F32GRDIR1 F32GRDIR1 F32GRDIR1 Forward ground directional element
PRO R32GRDIR2 R32GRDIR2 R32GRDIR2 Reverse ground directional element
PRO F32QRDIR3 F32QRDIR3 F32QRDIR3 Forward negative-sequence phase directional element
PRO R32QRDIR4 R32QRDIR4 R32QRDIR4 Reverse negative-sequence phase directional element
PRO F32PRDIR5 F32PRDIR5 F32PRDIR5 Forward phase directional element
PRO R32PRDIR6 R32PRDIR6 R32PRDIR6 Reverse phase directional element
PRO BFR1RBRF1 BFR1RBRF1 BFR1RBRF1 Circuit Breaker 1 circuit breaker failure
PRO BFR2RBRF2 BFR2RBRF2 BFR2RBRF2 Circuit Breaker 2 circuit breaker failure
PRO OSTRPSB1 OSTRPSB1 OSTRPSB1 Out-of-step tripping
PRO OSB1RPSB2 OSB1RPSB2 OSB1RPSB2 Block Zone 1 during an out-of-step condition
PRO OSB2RPSB3 OSB2RPSB3 OSB2RPSB3 Block Zone 2 during an out-of-step condition
PRO OSB3RPSB4 OSB3RPSB4 OSB3RPSB4 Block Zone 3 during an out-of-step condition
PRO OSB4RPSB5 OSB4RPSB5 OSB4RPSB5 Block Zone 4 during an out-of-step condition
PRO OSB5RPSB6 OSB5RPSB6 OSB5RPSB6 Block Zone 5 during an out-of-step condition
PRO BK1AXCBR1 BK1AXCBR1 BK1AXCBR1 Circuit Breaker 1, Pole A
PRO BK1BXCBR2 BK1BXCBR2 BK1BXCBR2 Circuit Breaker 1, Pole B
PRO BK1CXCBR3 BK1CXCBR3 BK1CXCBR3 Circuit Breaker 1, Pole C
PRO BK2AXCBR4 BK2AXCBR4 BK2AXCBR4 Circuit Breaker 2, Pole A
PRO BK2BXCBR5 BK2BXCBR5 BK2BXCBR5 Circuit Breaker 2, Pole B
PRO BK3CXCBR6 BK3CXCBR6 BK3CXCBR6 Circuit Breaker 2, Pole C
PRO BKR1CSWI1 BKR1CSWI1 BKR1CSWI1 Circuit Breaker 1
PRO BKR2CSWI2 BKR2CSWI2 BKR2CSWI2 Circuit Breaker 2
MET METMMXU1 METMMXU1 METMMXU1 Measured Values (Currents and Voltages)
MET SEQMSQI1 SEQMSQI1 SEQMSQI1 Positive and Zero-sequence currents and voltages
CON RBGGIO1 RBGGIO1 RBGGIO1 Remote Bits
ANN PSVGGIO1 PSVGGIO1 PSVGGIO1 Protection SEL
OGIC Control Variables
ANN PLTGGIO2 PLTGGIO2 PLTGGIO2 Protection Latches
ANN PMVGGIO3 PMVGGIO3 PMVGGIO3 Protection SEL
OGIC Control Equation Math Variables
ANN ASVGGIO4 ASVGGIO4 ASVGGIO4 Automation SEL
OGIC Control Equation Variables
ANN ALTGGIO5 ALTGGIO5 ALTGGIO5 Automation Latches
ANN AMVGGIO6 AMVGGIO6 AMVGGIO6 Automation SEL
OGIC Control Equation Math Variables
ANN TLEDGGIO7 TLEDGGIO7 TLEDGGIO7
b
Front panel target LEDs
ANN PBLEDGGIO8 PBLEDGGIO8 PBLEDGGIO8
b
Pushbutton LEDs
ANN RMBAGGIO9 RMBAGGIO9 RMBAGGIO9 Channel A Receive M
IRRORED BITS
Table 8.7 ICD Logical Nodes Summary (Sheet 2 of 3)
Logical
Device
Logical Nodes by ICD Version
Description
Ver 001
Ver 002L
Ver 002 Ver 002 R123+
