R.A.42
SEL-421 Relay Reference Manual Date Code 20111215
Relay Word Bits
Row List
Table A.22 Relay Word Bits: Remote Bits
Row Name Description
92 RB25 Remote Bit 25
92 RB26 Remote Bit 26
92 RB27 Remote Bit 27
92 RB28 Remote Bit 28
92 RB29 Remote Bit 29
92 RB30 Remote Bit 30
92 RB31 Remote Bit 31
92 RB32 Remote Bit 32
93 RB17 Remote Bit 17
93 RB18 Remote Bit 18
93 RB19 Remote Bit 19
93 RB20 Remote Bit 20
93 RB21 Remote Bit 21
93 RB22 Remote Bit 22
93 RB23 Remote Bit 23
93 RB24 Remote Bit 24
94 RB09 Remote Bit 9
94 RB10 Remote Bit 10
94 RB11 Remote Bit 11
94 RB12 Remote Bit 12
94 RB13 Remote Bit 13
94 RB14 Remote Bit 14
94 RB15 Remote Bit 15
94 RB16 Remote Bit 16
95 RB01 Remote Bit 1
95 RB02 Remote Bit 2
95 RB03 Remote Bit 3
95 RB04 Remote Bit 4
95 RB05 Remote Bit 5
95 RB06 Remote Bit 6
95 RB07 Remote Bit 7
95 RB08 Remote Bit 8
Table A.23 Relay Word Bits: Active Protection Settings Group (Sheet 1 of 2)
Row Name Description
96 SG6 Settings Group 6 active
96 SG5 Settings Group 5 active
96 SG4 Settings Group 4 active
96 SG3 Settings Group 3 active
96 SG2 Settings Group 2 active
96 SG1 Settings Group 1 active
