IEC 61850 Communications
Features
The SEL-421 Relay supports the following features using Ethernet and
IEC 61850:
➤ SCADA—Connect up to six simultaneous Ethernet client
sessions. The SEL-421 also supports up to six buffered and six
unbuffered report control blocks.
➤ Real-Time Status and Control—Use GOOSE with as many
as 24 incoming (receive) and 8 outgoing (transmit) messages.
NOTE: The SEL-421 supports one CID
file, which should be transferred only
if a change in the relay configuration
is required. If an invalid CID file is
transferred, the relay will no longer
have a valid IEC 61850 configuration,
and the protocol will stop operating.
To restart protocol operation, a valid
CID must be transferred to the relay.
➤ Configuration—Use FTP client software or ACSELERATOR
Architect
®
SEL-5032 Software to transfer the Substation
Configuration Language (SCL) Configured IED Description
(CID) file to the relay.
➤ Commissioning and Troubleshooting—Use software such as
MMS Object Explorer and AX-S4 MMS from Sisco, Inc., to
browse the relay logical nodes and verify functionality.
➤ Firmware Upgrades—Use FTP client software to transfer the
Ethernet port firmware upgrade file to the relay.
This section presents the information you need to use the IEC 61850 features
of the SEL-421:
➤ Introduction to IEC 61850 on page R.8.2
➤ IEC 61850 Operation on page R.8.3
➤ IEC 61850 Configuration on page R.8.12
➤ Logical Nodes on page R.8.16
➤ ACSI Conformance Statements on page R.8.37
