R.10.50
SEL-421 Relay Reference Manual Date Code 20111215
Settings
DNP3 Settings—Serial Port
DNP3 Settings—Serial Port
Make Table 10.103 settings if preceding setting DNPBID := N.
Make Table 10.104 settings if preceding setting DNPBOD := N.
Table 10.100 DNP3 Settings Categories
Settings Reference
DNP Reference Map Selection Table 10.101
DNP3 Object Default Map Enables Table 10.102
Binary Input Map Table 10.103
Binary Output Map Table 10.104
Counter Map Table 10.105
Analog Input Map Table 10.106
Analog Output Map Table 10.107
Table 10.101 DNP Reference Map Selection
Label Prompt Default Value
MAPSEL Reference Map Selection (B, E) B
Table 10.102 DNP3 Object Default Map Enables
Label Prompt Default Value
DNPBID Use default DNP map for Binary Inputs (Y, N) Y
DNPBOD Use default DNP map for Binary Outputs (Y, N) Y
DNPCOD Use default DNP map for Counters (Y, N) Y
DNPAID Use default DNP map for Analog Inputs (Y, N) Y
DNPAOD Use default DNP map for Analog Outputs (Y, N) Y
Table 10.103 Binary Input Map
Label Prompt Default Value
BI_MAPn
a
a
Parameter n indicates the index number for row 1 to 400; see Configurable Data Mapping on
page R.6.10.
Index Number (Valid binary input index number)
Tabl e 1 0 .10 4 B ina r y Ou t put M ap
Label Prompt Default Value
BO_MAPn
a
a
Parameter n indicates the index number for row 1 to 70; see Configurable Data Mapping on
page R.6.10.
Index Number (Valid binary output index number)
NOTE: See corresponding command
descriptions SET D on page R.9.41 and
SHO D on page R.9.45 to set or show
the DNP3 settings.
