Settings
DNP3 Settings—Serial Port
Make Table 10.105 settings if preceding setting DNPCOD := N.
Make Table 10.106 settings if preceding setting DNPAID := N.
Make Table 10.107 settings if preceding setting DNPAOD := N.
Table 10.105 Counter Map
Label Prompt Default Value
CO_MAPn
a
a
Parameter n indicates the index number for row 1 to 10; see Configurable Data Mapping on
page R.6.10.
Index Number (Valid counter index number)
CO_DBDn Deadband (1–32767) (ANADBx
b
port setting)
b
Parameter x is A, V, M representing currents, voltages, and miscellaneous, respectively.
Table 10.106 Analog Input Map
Label Prompt Default Value
AI_MAPn
a
a
Parameter n indicates the index number for row 1 to 200; see Configurable Data Mapping on
page R.6.10.
Index Number (Valid analog input index number)
AI_SCAn Scale Factor (0.001–1000.000) (DECPLx
b
port setting)
b
Parameter x is A, V, M representing currents, voltages, and miscellaneous, respectively.
AI_DBDn Deadband (1–32767) (ANADBx
port setting)
Tabl e 1 0 .10 7 A nal o g Ou t pu t Map
Label Prompt Default Value
AO_MAPn
a
a
Parameter n indicates the index number for row 1 or 2; see Configurable Data Mapping on
page R.6.10.
Index Number (Valid analog output index number)
