Sel SEL-421 - Relay Word Bits: Protection Latches

R.A.46
SEL-421 Relay Reference Manual Date Code 20111215
Relay Word Bits
Row List
114 PSV54 Protection SELOGIC Var iab le 5 4
114 PSV53 Protection SEL
OGIC Var i abl e 5 3
114 PSV52 Protection SEL
OGIC Var i abl e 5 2
114 PSV51 Protection SELOGIC Var iab le 5 1
114 PSV50 Protection SEL
OGIC Var i abl e 5 0
114 PSV49 Protection SEL
OGIC Var i abl e 4 9
115 PSV64 Protection SEL
OGIC Var i abl e 6 4
115 PSV63 Protection SEL
OGIC Var i abl e 6 3
115 PSV62 Protection SEL
OGIC Var i abl e 6 2
115 PSV61 Protection SEL
OGIC Var i abl e 6 1
115 PSV60 Protection SEL
OGIC Var i abl e 6 0
115 PSV59 Protection SEL
OGIC Var i abl e 5 9
115 PSV58 Protection SEL
OGIC Var i abl e 5 8
115 PSV57 Protection SEL
OGIC Var i abl e 5 7
Table A.26 Relay Word Bits: Protection Latches (Sheet 1 of 2)
Row Name Description
116 PLT08 Protection Latch 8
116 PLT07 Protection Latch 7
116 PLT06 Protection Latch 6
116 PLT05 Protection Latch 5
116 PLT04 Protection Latch 4
116 PLT03 Protection Latch 3
116 PLT02 Protection Latch 2
116 PLT01 Protection Latch 1
117 PLT16 Protection Latch 16
117 PLT15 Protection Latch 15
117 PLT14 Protection Latch 14
117 PLT13 Protection Latch 13
117 PLT12 Protection Latch 12
117 PLT11 Protection Latch 11
117 PLT10 Protection Latch 10
117 PLT09 Protection Latch 9
118 PLT24 Protection Latch 24
118 PLT23 Protection Latch 23
118 PLT22 Protection Latch 22
118 PLT21 Protection Latch 21
118 PLT20 Protection Latch 20
118 PLT19 Protection Latch 19
118 PLT18 Protection Latch 18
118 PLT17 Protection Latch 17
Table A.25 Relay Word Bits: Protection Variables (Sheet 3 of 3)
Row Name Description
