ASCII Command Reference
Description of Commands
SET L
Use the SET L command to set the Protection SELOGIC control equations.
See Section 3: SEL
OGIC Control Equation Programming for more information
on SEL
OGIC control equations.
The relay presents text-edit mode entry format for the free-form SEL
OGIC
control equations you program in the Protection SEL
OGIC control equation
settings area. See Text-Edit Mode Line Editing on page U.4.18 for information
on settings text-edit mode.
SET M
Use the SET M command to set the circuit breaker monitor settings. There is
only one instance for the Breaker Monitor class. See Section 2: Monitoring
and Metering in the Applications Handbook for information on the circuit
breaker monitor.
SET O
Use the SET O command to set the Output SELOGIC control equations. See
Control Outputs on page U.2.7 for more information on relay control outputs.
Table 9.105 SET G Command
Command Description Access Level
SET G Set the Global relay settings, beginning
at the first setting in this class.
P, A, O, 2
SET G label Set the Global relay settings, beginning
at the setting label label.
P, A, O, 2
Table 9.106 SET L Command
Command Description Access Level
SET L Set the Protection SELOGIC control equation
relay settings for the active settings group.
P, 2
SET L n
a
a
Parameter n is 1–6 for Protection Groups 1 through 6.
Set the Protection SELOGIC relay settings for
Instance n, which is Group n.
P, 2
Table 9.107 SET M Command
Command Description Access Level
SET M Set the Breaker Monitor relay settings, begin-
ning at the first setting in this class.
P, 2
SET M label Set the Breaker Monitor relay settings, begin-
ning at the settings label label.
P, 2
Table 9.108 SET O Command
Command Description Access Level
SET O Set the Output SELOGIC control equation relay
settings, beginning at OUT101.
O, 2
SET O label Set the Output SEL
OGIC control equation relay
settings, beginning at the output label label.
O, 2
