R.6.20
SEL-421 Relay Reference Manual Date Code 20111215
DNP3 Communications
DNP3 Documentation
With the base reference map, the Relay Word bits mapped into Objects 1 and
2 are shown in Table 6.11. For non-SER points in the range 0–799, use the
Index Range column directly. For SER points in the range 800–1599, add 800
to the indices in Table 6.11. The table lists eight bits in each row and the index
30, 32 136–139 Reserved
30, 32 140–143 Reserved
30, 32 144
a
Peak A-phase demand current (amps) (IAPKD)
b
30, 32 145
a
Peak B-phase demand current (amps) (IBPKD)
b
30, 32 146
a
Peak C-phase demand current (amps) (ICPKD)
b
30, 32 147
a
Peak zero-sequence demand current (amps) (IGPKD)
b
30, 32 148
a
Peak negative-sequence demand current (amps) (3I2PKD)
b
30, 32 149 Reserved
30, 32 150–153
d
A-phase, B-phase, C-phase and three-phase peak demand power (MW) (PAPKD, PBPKD,
PCPKD, 3PPKD)
b
30, 32 154–157 Reserved
30, 32 158–161 Reserved
30, 32 162–165 Reserved
30, 32 166–168 Circuit Breaker 1 contact wear percentage multiplied by 100 (B1BCWPA, B1BCWPB,
B1BCWPC)
b
30, 32 169–171 Circuit Breaker 2 contact wear percentage multiplied by 100 (B2BCWPA, B2BCWPB,
B2BCWPC)
b
30, 32 172–175 Reserved
30, 32
f
176 Fault type (Table 6. 13 and Table 6.14)
30, 32
f
177 Fault targets (Relay Word rows 0 and 1)
30, 32
f
178
e
Fault location
30, 32
f
179
a
Fault current
30, 32
f
180
e
Fault frequency (Hz)
30, 32
f
181 Fault settings group
30, 32
f
182 Fault targets (Relay Word row 280)
30, 32
f
183 Reserved
30, 32
f
184–186 Fault time in DNP format (high, middle, and low 16 bits)
30, 32
f
187 Reserved
30, 32
f
188 Three-pole reclose count
30, 32
f
189–195 Reserved
30, 32 196–227 First 32 automation math variables (AMV001–AMV032)
40, 41 0 Active settings group
40, 41 1 Time-error preload value (TECORR)
g
a
Default current scaling DECPLA on magnitudes and scale factor of 100 on angles. Dead band ANADBV on magnitudes and ANADBM on
angles.
b
Analog quantity labels.
c
Default voltage scaling DECPLV on magnitudes and scale factor of 100 on angles. Dead band ANADBV on magnitudes and ANADBM on
angles.
d
Default miscellaneous scaling DECPLM and dead band ANADBM.
e
Default scale factor of 100.
f
Event data shall only be generated for the fault summary information if the relay is operating in single event mode.
g
In milliseconds, –30000  time 30000. Relay Word bit PLDTE asserts for approximately 1.5 cycles after this value is written.
Tabl e 6 . 10 SEL -42 1 DNP3 Default Data Map (Sheet 4 of 4)
Object Indices Description
