R.6.22
SEL-421 Relay Reference Manual Date Code 20111215
DNP3 Communications
DNP3 Documentation
295–288
PSV16 PSV15 PSV14 PSV13 PSV12 PSV11 PSV10 PSV09
303–296
PSV24 PSV23 PSV22 PSV21 PSV20 PSV19 PSV18 PSV17
311–304
PSV32 PSV31 PSV30 PSV29 PSV28 PSV27 PSV26 PSV25
319–312
PLT08 PLT07 PLT06 PLT05 PLT04 PLT03 PLT02 PLT01
327–320
PLT16 PLT15 PLT14 PLT13 PLT12 PLT11 PLT10 PLT09
335–328
PCT08Q PCT07Q PCT06Q PCT05Q PCT04Q PCT03Q PCT02Q PCT01Q
343–336
PCT16Q PCT15Q PCT14Q PCT13Q PCT12Q PCT11Q PCT10Q PCT09Q
351–344
PST08Q PST07Q PST06Q PST05Q PST04Q PST03Q PST02Q PST01Q
359–352
PST16Q PST15Q PST14Q PST13Q PST12Q PST11Q PST10Q PST09Q
367–360
PCN08Q PCN07Q PCN06Q PCN05Q PCN04Q PCN03Q PCN02Q PCN01Q
375–368
PCN16Q PCN15Q PCN14Q PCN13Q PCN12Q PCN11Q PCN10Q PCN09Q
383–376
ASV008 ASV007 ASV006 ASV005 ASV004 ASV003 ASV002 ASV001
391–384
ASV016 ASV015 ASV014 ASV013 ASV012 ASV011 ASV010 ASV009
399–392
ASV024 ASV023 ASV022 ASV021 ASV020 ASV019 ASV018 ASV017
407–400
ASV032 ASV031 ASV030 ASV029 ASV028 ASV027 ASV026 ASV025
415–408
ALT08 ALT07 ALT06 ALT05 ALT04 ALT03 ALT02 ALT01
423–416
ALT16 ALT15 ALT14 ALT13 ALT12 ALT11 ALT10 ALT09
431–424
AST08Q AST07Q AST06Q AST05Q AST04Q AST03Q AST02Q AST01Q
439–432
AST16Q AST15Q AST14Q AST13Q AST12Q AST11Q AST10Q AST09Q
447–440
ACN08Q ACN07Q ACN06Q ACN05Q ACN04Q ACN03Q ACN02Q ACN01Q
455–448
ACN16Q ACN15Q ACN14Q ACN13Q ACN12Q ACN11Q ACN10Q ACN09Q
463–456
PUNRLBL PFRTEX MATHERR * * * * *
471–464
AUNRLBL AFRTEXP AFRTEXA * * * * *
479–472
SALARM HALARM BADPASS CCALARM * * * *
487–480
*** * * ***
495–488
* * * * * * * *
503–496
* * TIRIG TUPDH TSYNCA TSOK PMDOK FREQOK
511–504
OUT108 OUT107 OUT106 OUT105 OUT104 OUT103 OUT102 OUT101
519–512
OUT208 OUT207 OUT206 OUT205 OUT204 OUT203 OUT202 OUT201
527–520
OUT216 OUT215 OUT214 OUT213 OUT212 OUT211 OUT210 OUT209
535–528
OUT308 OUT307 OUT306 OUT305 OUT304 OUT303 OUT302 OUT301
543–536
OUT316 OUT315 OUT314 OUT313 OUT312 OUT311 OUT310 OUT309
551–544
PB1_LED PB2_LED PB3_LED PB4_LED PB5_LED PB6_LED PB7_LED PB8_LED
559–552
RMB8A RMB7A RMB6A RMB5A RMB4A RMB3A RMB2A RMB1A
567–560
TMB8A TMB7A TMB6A TMB5A TMB4A TMB3A TMB2A TMB1A
575–568
RMB8B RMB7B RMB6B RMB5B RMB4B RMB3B RMB2B RMB1B
583–576
TMB8B TMB7B TMB6B TMB5B TMB4B TMB3B TMB2B TMB1B
591–584
ROKA RBADA CBADA LBOKA ANOKA DOKA * *
599–592
ROKB RBADB CBADB LBOKB ANOKB DOKB * *
607–600
TESTDNP TESTDB TESTFM TESTPUL * * * *
Tabl e 6 . 11 SE L- 42 1
Object 1, 2 Relay Word Bit Mapping (Sheet 2 of 3)
Index Range
Relay Word Bits
a
7 6 5 4 3 2 1 0
