R.10.38
SEL-421 Relay Reference Manual Date Code 20111215
Settings
Front-Panel Settings
PB4_LED Pushbutton LED 4
(SEL
OGIC Equation)
PLT04 #RELAY TEST MODE
PB4_COL PB_LED Assert and Deassert Color
(Enter 2: R,G,A,O)
AO
PB5_LED Pushbutton LED 5
(SEL
OGIC Equation)
PLT05 #MANUAL CLOSE
ENABLED
PB5_COL PB_LED Assert and Deassert Color
(Enter 2: R,G,A,O)
AO
PB6_LED Pushbutton LED 6
(SEL
OGIC Equation)
PLT06 #RECLOSE ENABLED
PB6_COL PB_LED Assert and Deassert Color
(Enter 2: R,G,A,O)
AO
PB7_LED Pushbutton LED 7
(SEL
OGIC Equation)
52ACL1 AND 52AB1 AND
52AC1 #BREAKER CLOSED
(8 Pushbuttons)
0#AUX (12 Pushbuttons)
PB7_COL PB_LED Assert and Deassert Color
(Enter 2: R,G,A,O)
AO
PB8_LED Pushbutton LED 8
(SEL
OGIC Equation)
NOT (52ACL1 AND 52AB1
AND 52AC1) #BREAKER
OPEN (8 Pushbuttons)
0#AUX (12 Pushbuttons)
PB8_COL PB_LED Assert and Deassert Color
(Enter 2: R,G,A,O)
AO
PB9_LED
a
Pushbutton LED 9
(SEL
OGIC Equation)
0 #AUX
PB9_COL
a
PB_LED Assert and Deassert Color
(Enter 2: R,G,A,O)
AO
PB10LED
a
Pushbutton LED 10
(SEL
OGIC Equation)
0 #AUX
PB10COL
a
PB_LED Assert and Deassert Color
(Enter 2: R,G,A,O)
AO
PB11LED
a
Pushbutton LED 11
(SEL
OGIC Equation)
52ACL1 AND 52AB1 AND
52AC1 #BREAKER CLOSED
0 #AUX
(Auxiliary TRIP/CLOSE
Pushbuttons)
PB11COL
a
PB_LED Assert and Deassert Color
(Enter 2: R,G,A,O)
AO
PB12LED
a
Pushbutton LED 12
(SEL
OGIC Equation)
NOT (52ACL1 AND 52AB1
AND 52AC1) #BREAKER
OPEN
0 #AUX (Auxiliary TRIP/
CLOSE Pushbuttons)
PB12COL
a
PB_LED Assert and Deassert Color
(Enter 2: R,G,A,O)
AO
T1_LED Target LED 1
(SEL
OGIC Equation)
(M1P OR Z1G) AND NOT
(SOTFT OR TLED_3)
T1LEDL Target LED 1 Latch (Y, N) Y
T1LEDA Target LED 1 Alias (8 characters) INST
Table 10.79 Front Panel Settings (Sheet 2 of 6)
Label Prompt Default Value
