Settings
Front-Panel Settings
T1LEDC T_LED Assert and Deassert Color
(Enter 2: R,G,A,O)
RO
T2_LED Target LED 2
(SEL
OGIC Equation)
(M2PT OR Z2GT OR M3PT OR
Z3GT OR M4PT OR Z4GT)
AND NOT (TLED_1 OR
TLED_3 OR TLED_4)
T2LEDL Target LED 2 Latch (Y, N) Y
T2LEDA Target LED 2 Alias (8 characters) TIME
T2LEDC T_LED Assert and Deassert Color
(Enter 2: R,G,A,O)
RO
T3_LED Target LED 3
(SEL
OGIC Equation)
COMPRM AND NOT (M1P OR
Z1G OR TLED_1 OR SOTFT)
T3LEDL Target LED 3 Latch (Y, N) Y
T3LEDA Target LED 3 Alias (8 characters) COMM
T3LEDC T_LED Assert and Deassert Color
(Enter 2: R,G,A,O)
RO
T4_LED Target LED 4
(SEL
OGIC Equation)
SOTFT
T4LEDL Target LED 4 Latch (Y, N) Y
T4LEDA Target LED 4 Alias (8 characters) SOTF
T4LEDC T_LED Assert and Deassert Color
(Enter 2: R,G,A,O)
RO
T5_LED Target LED 5
(SEL
OGIC Equation)
(M1P OR Z1G) AND NOT
(TLED_6 OR TLED_7 OR
TLED_8)
T5LEDL Target LED 5 Latch (Y, N) Y
T5LEDA Target LED 5 Alias (8 characters) ZONE_1
T5LEDC T_LED Assert and Deassert Color
(Enter 2: R,G,A,O)
RO
T6_LED Target LED 6
(SEL
OGIC Equation)
(M2P OR Z2G) AND NOT
(M1P OR Z1G OR TLED_5)
T6LEDL Target LED 6 Latch (Y, N) N
T6LEDA Target LED 6 Alias (8 characters) ZONE_2
T6LEDC T_LED Assert and Deassert Color
(Enter 2: R,G,A,O)
RO
T7_LED Target LED 7
(SEL
OGIC Equation)
(M3P OR Z3G) AND NOT
(M1P OR M2P OR Z1G OR
Z2G OR TLED_5 OR TLED_6)
T7LEDL Target LED 7 Latch (Y, N) N
T7LEDA Target LED 7 Alias (8 characters) ZONE_3
T7LEDC T_LED Assert and Deassert Color
(Enter 2: R,G,A,O)
RO
T8_LED Target LED 8
(SEL
OGIC Equation)
(M4P OR Z4G) AND NOT
(M1P OR M2P OR M3P OR
Z1G OR Z2G OR Z3G OR
TLED_5 OR TLED_6 OR
TLED_7)
T8LEDL Target LED 8 Latch (Y, N) N
Table 10.79 Front Panel Settings (Sheet 3 of 6)
