R.10.40
SEL-421 Relay Reference Manual Date Code 20111215
Settings
Front-Panel Settings
T8LEDA Target LED 8 Alias (8 characters) ZONE_4
T8LEDC T_LED Assert and Deassert Color
(Enter 2: R,G,A,O)
RO
T9_LED Target LED 9
(SEL
OGIC Equation)
PHASE_A
T9LEDL Target LED 9 Latch (Y, N) Y
T9LEDA Target LED 9 Alias (8 characters) A_PHASE
T9LEDC T_LED Assert and Deassert Color
(Enter 2: R,G,A,O)
RO
T10_LED Target LED 10
(SEL
OGIC Equation)
PHASE_B
T10LEDL Target LED 10 Latch (Y, N) Y
T10LEDA Target LED 10 Alias (8 characters) B_PHASE
T10LEDC T_LED Assert and Deassert Color
(Enter 2: R,G,A,O)
RO
T11_LED Target LED 11
(SEL
OGIC Equation)
PHASE_C
T11LEDL Target LED 11 Latch (Y, N) Y
T11LEDA Target LED 11 Alias (8 characters) C_PHASE
T11LEDC T_LED Assert and Deassert Color
(Enter 2: R,G,A,O)
RO
T12_LED Target LED 12
(SEL
OGIC Equation)
GROUND
T12LEDL Target LED 12 Latch (Y, N) Y
T12LEDA Target LED 12 Alias (8 characters) GROUND
T12LEDC T_LED Assert and Deassert Color
(Enter 2: R,G,A,O)
RO
T13_LED Target LED 13
(SEL
OGIC Equation)
50P1 OR 50P2 OR 50P3 OR
50P4 OR 50Q1 OR 50Q2 OR
50Q3 OR 50Q4 OR 50G1 OR
50G2 OR 50G3 OR 50G4
T13LEDL Target LED 13 Latch (Y, N) Y
T13LEDA Target LED 13 Alias (8 characters) 50
T13LEDC T_LED Assert and Deassert Color
(Enter 2: R,G,A,O)
RO
T14_LED Target LED 14
(SEL
OGIC Equation)
51S1T OR 51S2T OR 51S3T
T14LEDL Target LED 14 Latch (Y, N) Y
T14LEDA Target LED 14 Alias (8 characters) 51
T14LEDC T_LED Assert and Deassert Color
(Enter 2: R,G,A,O)
RO
T15_LED Target LED 15
(SEL
OGIC Equation)
BK1RS
T15LEDL Target LED 15 Latch (Y, N) N
T15LEDA Target LED 15 Alias (8 characters) 79_RESET
T15LEDC T_LED Assert and Deassert Color
(Enter 2: R,G,A,O)
RO
Table 10.79 Front Panel Settings (Sheet 4 of 6)
Label Prompt Default Value
