Sel SEL-421 - Page 559

R.10.41
Date Code 20111215 Reference Manual SEL-421 Relay
Settings
Front-Panel Settings
T16_LED Target LED 16
(SEL
OGIC Equation)
BK1LO
T16LEDL Target LED 16 Latch (Y, N) N
T16LEDA Target LED 16 Alias (8 characters) 79_LO
T16LEDC T_LED Assert and Deassert Color
(Enter 2: R,G,A,O)
RO
T17_LED
b
Target LED 17
(SEL
OGIC Equation)
79CY1 OR 79CY3
T17LEDL
b
Target LED 17 Latch (Y, N) N
T17LEDA
b
Target LED 17 Alias (8 characters) 79_CYCLE
T17LEDC
b
T_LED Assert and Deassert Color
(Enter 2: R,G,A,O)
RO
T18_LED
b
Target LED 18
(SEL
OGIC Equation)
25A1BK1
T18LEDL
b
Target LED 18 Latch (Y, N) N
T18LEDA
b
Target LED 18 Alias (8 characters) 25_SYNCH
T18LEDC
b
T_LED Assert and Deassert Color
(Enter 2: R,G,A,O)
RO
T19_LED
b
Target LED 19
(SEL
OGIC Equation)
BK1CL
T19LEDL
b
Target LED 19 Latch (Y, N) N
T19LEDA
b
Target LED 19 Alias (8 characters) BK1_CLS
T19LEDC
b
T_LED Assert and Deassert Color
(Enter 2: R,G,A,O)
RO
T20_LED
b
Target LED 20
(SEL
OGIC Equation)
BFTRIP1
T20LEDL
b
Target LED 20 Latch (Y, N) N
T20LEDA
b
Target LED 20 Alias (8 characters) BK1_FAIL
T20LEDC
b
T_LED Assert and Deassert Color
(Enter 2: R,G,A,O)
RO
T21_LED
b
Target LED 21
(SEL
OGIC Equation)
OSB
T21LEDL
b
Target LED 21 Latch (Y, N) N
T21LEDA
b
Target LED 21 Alias (8 characters) OSB
T21LEDC
b
T_LED Assert and Deassert Color
(Enter 2: R,G,A,O)
RO
T22_LED
b
Target LED 22
(SEL
OGIC Equation)
LOP
T22LEDL
b
Target LED 22 Latch (Y, N) N
T22LEDA
b
Target LED 22 Alias (8 characters) LOP
T22LEDC
b
T_LED Assert and Deassert Color
(Enter 2: R,G,A,O)
RO
T23_LED
b
Target LED 23
(SEL
OGIC Equation)
PMDOK AND TSOK
T23LEDL
b
Target LED 23 Latch (Y, N) N
T23LEDA
b
Target LED 23 Alias (8 characters) PM_OK
Table 10.79 Front Panel Settings (Sheet 5 of 6)
Label Prompt Default Value
