DNP3 Communications
DNP3 Documentation
31 2 16-Bit Frozen Analog Input
31 3 32-Bit Frozen Analog Input With Time of Freeze
31 4 16-Bit Frozen Analog Input With Time of Freeze
31 5 32-Bit Frozen Analog Input Without Flag
31 6 16-Bit Frozen Analog Input Without Flag
32 0 Analog Change Event—All Variations 1 6, 7, 8
32 1 32-Bit Analog Change Event Without Time 1 6, 7, 8 129 17, 28
32 2
e
16-Bit Analog Change Event Without Time 1 6, 7, 8 129, 130 17, 28
32 3 32-Bit Analog Change Event With Time 1 6, 7, 8 129 17, 28
32 4 16-Bit Analog Change Event With Time 1 6, 7, 8 129 17, 28
33 0 Frozen Analog Event—All Variations
33 1 32-Bit Frozen Analog Event Without Time
33 2 16-Bit Frozen Analog Event Without Time
33 3 32-Bit Frozen Analog Event With Time
33 4 16-Bit Frozen Analog Event With Time
40 0 Analog Output Status—All Variations 1 0, 1, 6, 7, 8
40 1 32-Bit Analog Output Status 1 0, 1, 6, 7, 8 129 0, 1, 7, 8
40 2
e
16-Bit Analog Output Status 1 0, 1, 6, 7, 8 129 0, 1, 7, 8
41 0 Analog Output Block—All Variations
41 1 32-Bit Analog Output Block 3, 4, 5, 6 17, 28 129 echo of request
41 2 16-Bit Analog Output Block 3, 4, 5, 6 17, 28 129 echo of request
50 0 Time and Date—All Variations
50 1 Time and Date 1, 2 7, 8
index=0
129 07,
quanity=1
50 2 Time and Date With Interval
51 0 Time and Date CTO—All Variations
51 1 Time and Date CTO
51 2 Unsynchronized Time and Date CTO 07,
quanity=1
52 0 Time Delay—All Variations
52 1 Time Delay, Coarse
52 2 Time Delay, Fine 129 07,
quantity=1
60 0 All Classes of Data 1, 20, 21 6
60 1 Class 0 Data 1 6
60 2 Class 1 Data 1, 20, 21 6, 7, 8
60 3 Class 2 Data 1, 20, 21 6, 7, 8
60 4 Class 3 Data 1, 20, 21 6, 7, 8
70 1 File Identifier
80 1 Internal Indications 2 0, 1
index=7
Table 6.9 SEL-421 DNP Object List (Sheet 3 of 4)
Obj. Var. Description
Request
a
Response
b
Funct. Codes
c
Qual. Codes
d
Funct. Codes
c
Qual. Codes
d
