R.7.23
Date Code 20111215 Reference Manual SEL-421 Relay
Synchrophasors
Synchrophasor Analog Quantities
IAWPMID, IBWPMID,
ICWPMID
Aligned local current imaginary component
(I_W terminal)
A
a
IAXPMMD, IBXPMMD,
ICXPMMD
Aligned local current magnitude
(I_X terminal)
A
a
IAXPMAD, IBXPMAD,
ICXPMAD
Aligned local current angle (I_X terminal) degrees
IAXPMRD, IBXPMRD,
ICXPMRD
Aligned local current real component
(I_X terminal)
A
a
IAXPMID, IBXPMID,
ICXPMID
Aligned local current imaginary component
(I_X terminal)
A
a
IASPMMD, IBSPMMD,
ICSPMMD
Aligned local current magnitude
(I_W + I_X terminals)
A
a
IASPMAD, IBSPMAD,
ICSPMAD
Aligned local current angle
(I_W + I_X terminals)
degrees
IASPMRD, IBSPMRD,
ICSPMRD
Aligned local current real component
(I_W + I_X terminal)
A
a
IASPMID, IBSPMID,
ICSPMID
Aligned local current imaginary component
(I_W + I_X terminal)
A
a
I1WPMMD Aligned local positive-sequence current
magnitude (I_W terminal)
A
a
I1WPMAD Aligned local positive-sequence current
angle (I_W terminal)
degrees
I1WPMRD Aligned local positive-sequence current real
component (I_W terminal)
A
a
I1WPMID Aligned local positive-sequence current
imaginary component (I_W terminal)
A
a
I1XPMMD Aligned local positive-sequence current
magnitude (I_X terminal)
A
a
I1XPMAD Aligned local positive-sequence current
angle (I_X terminal)
degrees
I1XPMRD Aligned local positive-sequence current real
component (I_X terminal)
A
a
I1XPMID Aligned local positive-sequence current
imaginary component (I_X terminal)
A
a
I1SPMMD Aligned local positive-sequence current
magnitude (I_W + I_X terminal)
A
a
I1SPMAD Aligned local positive-sequence current
angle (I_W + I_X terminal)
degrees
I1SPMRD Aligned local positive-sequence current real
component (I_W + I_X terminal)
A
a
I1SPMID Aligned local positive-sequence current
imaginary component (I_W + I_X terminal)
A
a
VALPMMD, VBLPMMD,
VCLPMMD
Aligned local voltage magnitude kV
a
VALPMAD, VBLPMAD,
VCLPMAD
Aligned local voltage angle degrees
VALPMRD, VBLPMRD,
VCLPMRD
Aligned local voltage real component kV
a
VALPMID, VBLPMID,
VCLPMID
Aligned local voltage imaginary component kV
a
Table 7.14 Synchrophasor Aligned Analog Quantities (Sheet 2 of 3)
Name Description Units
