R.8.25
Date Code 20111215 Reference Manual SEL-421 Relay
IEC 61850 Communications
Logical Nodes
AMVGGIO6 AMVGGIO6 AMVGGIO6 AnIn07.mag AMV07
AMVGGIO6 AMVGGIO6 AMVGGIO6 AnIn08.mag AMV08
AMVGGIO6 AMVGGIO6 AMVGGIO6 AnIn09.mag AMV09
AMVGGIO6 AMVGGIO6 AMVGGIO6 AnIn10.mag AMV10
……………
AMVGGIO6 AMVGGIO6 AMVGGIO6 AnIn63.mag AMV63
AMVGGIO6 AMVGGIO6 AMVGGIO6 AnIn64.mag AMV64
TLEDGGIO7 TLEDGGIO7 TLEDGGIO7 Ind01.stVal EN Front-panel target LED “EN”
TLEDGGIO7 TLEDGGIO7 TLEDGGIO7 Ind02.stVal TRIPLED Front-panel target LED “TRIPLED”
TLEDGGIO7 TLEDGGIO7 TLEDGGIO7 Ind03.stVal TLED_1 Front-panel target LED “TLED_1”
TLEDGGIO7 TLEDGGIO7 TLEDGGIO7 Ind04.stVal TLED_2 Front-panel target LED “TLED_2”
TLEDGGIO7 TLEDGGIO7 TLEDGGIO7 Ind05.stVal TLED_3 Front-panel target LED “TLED_3”
TLEDGGIO7 TLEDGGIO7 TLEDGGIO7 Ind06.stVal TLED_4 Front-panel target LED “TLED_4”
TLEDGGIO7 TLEDGGIO7 TLEDGGIO7 Ind07.stVal TLED_5 Front-panel target LED “TLED_5”
TLEDGGIO7 TLEDGGIO7 TLEDGGIO7 Ind08.stVal TLED_6 Front-panel target LED “TLED_6”
TLEDGGIO7 TLEDGGIO7 TLEDGGIO7 Ind09.stVal TLED_7 Front-panel target LED “TLED_7”
TLEDGGIO7 TLEDGGIO7 TLEDGGIO7 Ind10.stVal TLED_8 Front-panel target LED “TLED_8”
TLEDGGIO7 TLEDGGIO7 TLEDGGIO7 Ind11.stVal TLED_9 Front-panel target LED “TLED_9”
TLEDGGIO7 TLEDGGIO7 TLEDGGIO7 Ind12.stVal TLED_10 Front-panel target LED “TLED_10”
TLEDGGIO7 TLEDGGIO7 TLEDGGIO7 Ind13.stVal TLED_11 Front-panel target LED “TLED_11”
TLEDGGIO7 TLEDGGIO7 TLEDGGIO7 Ind14.stVal TLED_12 Front-panel target LED “TLED_12”
TLEDGGIO7 TLEDGGIO7 TLEDGGIO7 Ind15.stVal TLED_13 Front-panel target LED “TLED_13”
TLEDGGIO7 TLEDGGIO7 TLEDGGIO7 Ind16.stVal TLED_14 Front-panel target LED “TLED_14”
TLEDGGIO7 TLEDGGIO7 TLEDGGIO7 Ind17.stVal TLED_15 Front-panel target LED “TLED_15”
TLEDGGIO7 TLEDGGIO7 TLEDGGIO7 Ind18.stVal TLED_16 Front-panel target LED “TLED_16”
- - TLEDGGIO7
a
Ind19.stVal TLED_17 Front-panel target LED “TLED_17”
- - TLEDGGIO7
a
Ind20.stVal TLED_18 Front-panel target LED “TLED_18”
- - TLEDGGIO7
a
Ind21.stVal TLED_19 Front-panel target LED “TLED_19”
- - TLEDGGIO7
a
Ind22.stVal TLED_20 Front-panel target LED “TLED_20”
- - TLEDGGIO7
a
Ind23.stVal TLED_21 Front-panel target LED “TLED_21”
- - TLEDGGIO7
a
Ind24.stVal TLED_22 Front-panel target LED “TLED_22”
- - TLEDGGIO7
a
Ind25.stVal TLED_23 Front-panel target LED “TLED_23”
- - TLEDGGIO7
a
Ind26.stVal TLED_24 Front-panel target LED “TLED_24”
PBLEDGGIO8 PBLEDGGIO8 PBLEDGGIO8 Ind01.stVal PB1_LED Pushbutton LED “PB1_LED”
PBLEDGGIO8 PBLEDGGIO8 PBLEDGGIO8 Ind02.stVal PB2_LED Pushbutton LED “PB2_LED”
PBLEDGGIO8 PBLEDGGIO8 PBLEDGGIO8 Ind03.stVal PB3_LED Pushbutton LED “PB3_LED”
PBLEDGGIO8 PBLEDGGIO8 PBLEDGGIO8 Ind04.stVal PB4_LED Pushbutton LED “PB4_LED”
PBLEDGGIO8 PBLEDGGIO8 PBLEDGGIO8 Ind05.stVal PB5_LED Pushbutton LED “PB5_LED”
PBLEDGGIO8 PBLEDGGIO8 PBLEDGGIO8 Ind06.stVal PB6_LED Pushbutton LED “PB6_LED”
Table 8.11 Logical Device: ANN (Annunciation) (Sheet 4 of 9)
Logical Nodes by ICD Version
Attribute
Relay Word
or Database
Bit
Comment
Ver 001
Ver 002L
Ver 002 Ver 002 R123+
