SEL-421 Relay Reference Manual Date Code 20111215
Relay Word Bits
Row List
Table A.34 Relay Word Bits: SELOGIC Control Equation Error and Status
Row Name Description
194 PUNRLBL Protection SELOGIC control equation unresolved label
194 PFRTEX Protection SEL
OGIC control equation first execution
194 MATHERR SELOGIC control equation math error
194 * Reserved
194 * Reserved
194 * Reserved
194 * Reserved
194 * Reserved
195 * Reserved
195 * Reserved
195 * Reserved
195 * Reserved
195 * Reserved
195 * Reserved
195 * Reserved
195 * Reserved
196 AUNRLBL Automation SEL
OGIC control equation unresolved label
196 AFRTEXP Automation SEL
OGIC control equation first execution after
Protection Settings Change, Group Switch, or Source
Switch Selection.
196 AFRTEXA Automation SEL
OGIC control equation first execution after
Automation Settings change
196 * Reserved
196 * Reserved
196 * Reserved
196 * Reserved
196 * Reserved
197 * Reserved
197 * Reserved
197 * Reserved
197 * Reserved
197 * Reserved
197 * Reserved
197 * Reserved
197 * Reserved
