Operation - Refueling the machine
6 - 88
830 / 07.2012
Original operating instructions
DANGER
If the cap is not open, excess pressure can build up in the tank while it
is being filled. The tank can become deformed or can burst and
potentially cause damage to property or injure personnel. Spilled fuel
also causes environmental damage.
Note
Risk of cavitation!
Ensure that the maximum suction height of 3 m (3.28 ft) is not exceeded.
CAUTION
Ensure that the pump does not run dry (> 30 s).
Switch off the refueling pump with the red button (4) if necessary to
prevent damage.
6 Insert the refueling hose (2) in the external fuel container.
7 Switch on the refueling pump with the green button (3).
The tank is filled automatically.
8 The refueling pump switches off automatically as soon as the
tank is full.
9
Remove the refueling hose (2) from the external fuel tank and stow.
10 Re-close the cover of the filler strainer.
11 Close the service access door again.
