Operation - Refueling the machine
6 - 89
830 / 07.2012
Original operating instructions
Note
Check the following points if the refueling pump does not start after
approx. 5 seconds:
Using a refueling pump
(mast)
*: Optional model/special function
1 Is the battery charged?
2 Are all fuses in order?
3 Is the suction side free of leaks?
4 Is the maximum suction height 3 m or less?
1 Lower attached loads and the boom to the ground.
2 Shut down the engine.
3 Move the key switch to the āPā position.
4 Open the filler strainer cap.
This will allow air to escape from the fuel tank.
5 Open the doors (1) of the box for the refueling pump.
6 Insert the refueling hose (2) in the external fuel container.
